28 Configuration
TABLE MENU
Menu
Item
Restores K-Factor
table to factory
RECAL
default values to
allow entry of new
calibration data.
POINTS Number of points
Frequency points
2 – 20. Follow
monotonic and
FR 01
separation rules.
K 01 K factor points 2 -
20
MODBUS MENU
Menu Item
ADDRSS
BAUD
HP-327
Description
Description
Modbus address
Baud rate for
RS485
*Currently fixed at 9600.
Options
Value
NO
YES
2-20
Numeric 0.001
Entry 5000.000
Numeric 0.001
Entry 9999999.9
Options
Max
Value
Numeric 000-254
entry
*9600
57600
115200
Min Default
Max
N/A NO
2 10
20
Fr20 =
5000.000
Fr19=
4999.999
Fr18
=49999.998
ETC.
1.000
Min Default
N/A 9600
HIT-4U
