OUTPUT MENU
Menu Item
ANALOG
OUT LO
OUT HI
PULSE
WIDTH
SCALE
HIT-4U
Description
Analog Out
Function.
4 mA setting in
units selected
for Total .
OUT LO must
be < OUT HI.
20 mA setting in
units selected
for Total. OUT
HI must be >
OUT LO.
Pulse Function
Pulse width in
mS
Pulse Scale.
This factor
represents the
number of
output pulses
per least
significant digit
of displayed
total determined
by the total
decimal
selection.
Configuration 29
Options
OFF
RATE
4mA
12mA
20mA
Numeric
Entry
Numeric
Entry
OFF
ON
TEST
Numeric
Entry
0.01
0.1
1
10
100
Min Default
Max
Value
N/A OFF
0.000 0.000
999998
0.001 100.000
999999
N/A OFF
4 ms 4 ms
300 ms
N/A
HP-327
1
