PROGRAMMING AND RUNNING THE PUMP

THESE INSTRUCTIONS ARE NOT A SUBSTITUTE FOR THE OPERATOR'S MANUAL
Be sure to read the operator's manual thoroughly prior to operating the
pump. See other side for delivery set priming and loading instructions.
STEP 1
Hang feeding container so that the bottom of the bag
is at or above the level of the pump door.
STEP 2
Press and hold ON/OFF
running the self test, display will show last programmed rate.
STEP 3
Program the prescribed rate using the
STEP 4
Press RATE/DOSE
prescribed dose using the
STEP 5
Press the FOOD TYPE
to be delivered. Press the
change between formula and human milk.
STEP 6
Insert stepped connector into patient's feeding tube.
4 For a feeding tube without the ENFit® connection system,
use pre-attached transitional connector to connect set to
the feeding tube. Note: If transitional connector has become
detached from the set or is loose, screw it clockwise onto
the set firmly by hand. Be careful not to overtighten.
4 For a feeding tube with the ENFit® connection
system, remove pre-attached transitional connector
from set and screw set clockwise into feeding tube
firmly by hand. Be careful not to overtighten.
STEP 7
RUN/PAUSE
Press
STEP 8
When feeding is complete, press
for 1.5 seconds to turn the pump off.
NOTE: User must confirm each parameter (rate, dose, and food type) before pump
will start. If dose and food type are viewed prior to pressing the RUN/ PAUSE
key, pump will alarm and display CON FIRM DOSE AND FOOD TYPE.
NOTE: Rate, dose, and food type settings can be locked so that changes cannot be made. See the User
Preference Settings section of the Infinity Orange Operator's Manual for additional information.
key for 1.5 seconds to turn pump on. After
( + )
key to display dose. Program the
( + ) and ( – )
key to display type of food
( + ) and ( – ) keys to
key to start the pump.
ON/OFF
and ( – ) keys.
keys.
key
