IntesisBox DK-RC-MBS-1 User Manual page 8

Register Address
(protocol address)
6
7
8
9
10
11
22
23
26
55
97
4 This value is stored in non-volatile memory
5
See section 7 for possible error codes and their explanation
6 See section 4.2.3 for more information
7 This register is available in firmware version 0.8 onwards
8 If the register is configured as "0: Non-blocked", all commands received from Modbus will be sent to the AC system. If "1: Blocked",
commands from Modbus will only be sent to the AC system if they differ from the previous value.
9
This register applies to firmware version 1.6 onwards
© Intesis Software S.L.U. - All rights reserved
This information is subject to change without notice
IntesisBox ® is a registered trademark of Intesis Software SLU
DK-RC-MBS-1
Register Address
(PLC address)
7
8
9
10
11
12
23
24
27
56
98
R/W Description
Window Contact
R/W
0: Closed (Default)
▪
1: Open
▪
DK-RC-MBS-1 Disablement
R/W
0: DK-RC-MBS-1 enabled (Default value)
▪
1: DK-RC-MBS-1 disabled
▪
AC Remote Control Disablement
R/W
0: Remote Control enabled (Default value)
▪
1: Remote Control disabled
▪
AC unit Operation Time
R/W
0..65535 (hours). Counts the time the AC
▪
unit is in "On" state.
AC unit Alarm Status
R
0: No alarm condition
▪
1: Alarm condition
▪
Error Code 5
0: No error present
▪
65535(-1 if it is read as signed value): Error
▪
R
in the communication of DK-RC-MBS-1 with
the AC unit.
Any other error present, see the table at the
▪
end of this document.
Indoor unit´s ambient temperature from
external sensor (at Modbus side)
-32768: (Initialization value). No
▪
R/W
temperature is being provided from an
external sensor.
Any other: (ºC/x10ºC/ºF)
▪
AC Real temperature setpoint
When no external temperature is provided,
▪
this read-only register will have the same
value as register 5 (PLC addressing). In all
R
cases, it will show the current setpoint in the
indoor unit.
16..31ºC (ºC/x10ºC)
▪
60..90ºF
▪
AC unit Horizontal Vane Position
R/W
0: Auto (Default Value)
▪
10: Swing
▪
Under voltage counter
R/W
0..300
▪
Block Periodic Sendings
R/W
0: Non-blocked (Default value)
▪
1: Blocked
▪
URL
Email
Phone
User's Manual r3.3 EN
4
4
4
1,2,3,6,7
1,2,3,6
1
1
4,8,9
http://www.intesisbox.com
info@intesisbox.com
+34 938047134
8/23
