4. Modbus Interface Specification

4.1 Modbus physical layer

ME-AC-MBS-1 implements a Modbus RTU (Slave) interface, to be connected to an EIA-485 line.
It performs 8N2 communication (8 data bits, no parity and 2 stop bit) with several available
baud rates (2400 bps, 4800 bps, 9600 bps -default-, 19200 bps, 38400 bps, 57600 bps, 76800
bps and 115200 bps). It also supports 8N1 communication (8 data bits, no parity and 1 stop
bit).

4.2 Modbus Registers

All registers are type "16-bit unsigned Holding Register" and they use the standard Modbus big
endian notation.

4.2.1 Control and status registers

Register Address
(protocol address)
0
1
2
3
4
5
1 Available values will depend on the AC unit mode. Check the AC unit model functions in its User's Manual to know the possible values
for this register.
2 Magnitude for this register can be adjusted to Celsius x 1ºC, Celsius x 10ºC (Default) or Fahrenheit. See section 4.2.3 for more
information
3
It is not possible turn to x10 the value shown in Fahrenheit.
