DFRobot HCR Instruction Manual page 3

目录 Contents
电机装配......................................................................................1
Motor Assembly
万向轮装配..................................................................................2
Caster Assembly
底层装配......................................................................................3-7
Bottom Assembly
中层侧板装配..............................................................................8
The Second Level Side Assembly
中层装配......................................................................................9
The Second Level Assembly
上层装配......................................................................................10
The Third Level Assembly
Kinect支架装配..........................................................................11
Kinect Level Assembly
整机组装......................................................................................12
Final Platform Assembly
零部件清单..................................................................................13
Parts List
HCR Assembly Diagram
