- Page 1 切诺基初级套件 Cherokey 4WD Basic Kit 安装手册 Instruction Manual...
- Page 2 零件清单 Parts List...
- Page 3 零件清单 Parts List M2.5*25mm A1 x8 M3*6mm B1 x29 M3*30mm C3 x6 十字圆头螺钉 十字平头螺钉 尼龙柱 Phillips Pan Head Machine Screw Phillips Pan Head Machine Screw Nylon PCB Standoff M2.5 A2 x8 B2 x9 M3*8m C4 x2 平垫圈 螺母 十字平头螺钉 Flat Washer Phillips Flat Hrad Machine Screw M2.5 A3 x8...
- Page 4 工具列表 Tools List 主要工具 Essential Tools 十字螺丝刀 尖嘴钳 Phillips Screwdriver Long-Nosed Pliers 可选工具 Optional Too 电烙铁 拔线钳 Soldering Iron Wire Strippers （备注：本套件不包含工具和电池。） (Note: Tools and Batteries not included.)
- Page 5 安装电机与支架 Motor Installation 安装电机前，请先焊接电机线。 Solder power cables before installing the motors.
- Page 6 安装电池盒 Battery Box Installation...
- Page 7 安装主控板 Main Board Installation 为了便于后续安装，请将电机线穿过扩展板通孔。 Lead motor power cables through holes to keep it neat and tidy.
- Page 8 安装轮胎 Wheel Installation...
