HP
Model Number
1/2
SS1XN-1⁄2
3/4
SS1XN-3⁄4
3/4
SS1XS-3⁄4
1
SS1XN-1
1
SS1XS-1
1-1/2
SS1XN-11⁄2
1-1/2
SS1XS-11⁄2
2
SS11⁄4XN-2
2
SS1XS-2
2-1/2
SS11⁄4XN-21⁄2
2-1/2
SS1XS-21⁄2
* 230 Volt only.
For best possible performance and continuous, satisfactory
operation, read these instructions before installing your new pump.
Should service be required, this manual can be a valuable guide. It
should be kept near the installation for ready reference.
293 WRIGHT STREET, DELAVAN, WI 53115 WWW.BERKELEYPUMPS.COM
PH: 888-782-7483
© 2013 Pentair, Ltd. All Rights Reserved.
SSCX, SSCXS Series
ODP MOTORS
115/230/60/1
208-230/460/60/3
B78635
B78637
B82411
B78639
B82415
B78641
B82419
B78643*
B82423*
B78645*
B82427*
Important
High Head Centrifugal Pump
3342 1198 ASB
115/230/60/1
B78636
B78647
B78638
B78649
B82412
B82413
B78640
B78651
B82416
B82417*
B78642
B78653*
B82420
B82421
B78644
B78655*
B82424
B82425*
B78646
B78657*
B82428
B82429*
OWNER'S MANUAL
TEFC MOTORS
208-230/460/60/3
B78648
B78650
B82414
B78652
B82418
B78654
B82422
B78656
B82426
B78658
B82430
BE495 (Rev. 03/21/13)
