Part Description - JessEm Tool TA FENCE Owner's Manual

Item No. Part No.
1 E0256-1-6-C
2 E0257-2-6-C
3 E0258-1-6-C
4 M0280
5 E0255-1-3-C
6 F0364
7 F0363
8 F0365
9 E0253-1-6-C
10 E0254-1-6-C
11 M0329
12 M0328
13 E0210-2-3-C
14 E0252-1-3-C
15 F0369
16 F0352
17 F0330
18 F0028
19 F0347
20 F0348
21 E0274-1-3-C
22 F0366
23 E0205-3-3-C
24 E0002-12-3-C
25 S0004-22-C
26 E0206-2-3-C
27 S0053-18-C
28 S0027-2-C
29 E0002-12-3-C
30 S0053-17-C
31 M0286
32 F0376
33 F0094
34 S0014-5-C
35 S0006-1-C
36 S0006-2-C
37 F0367
38 F0368
39 F0370
40 S0054-4-C
41 F0052
42 E0211-4-6-C
43 E0083-3-3-C
44 E0245-1-6-C
45 E0054-23-3-C
46 E0257-1-6-C
47 S0053-13-C
48 S0062-7-C
49 E0083-5-3-C
50 E0205-6-3-C
51 E0205-7-3-C
52 S0052-2-C
53 S0054-3-C
54 E0252-1-3-C

Part Description

Upper Fence
Infeed Fence Body (Right)
Fence Base
Fence Vacuum Shroud
Fence Face Hard Anodized
10-24 X 3/4 Flat Head Torx Drive Machine Screw S.S.
10-24 X 1/2 Pan Head Torx Drive Machine Screw S.S.
1/4-20 X 1 Pan Head Torx Drive Machine Screw S.S.
Track Mounting Bar (Left and Right)
Fence Track (Left and Right)
Left Hand Track Cap
Right Hand Track Cap
Infeed Knob Retainer
Outfeed Scale Bar
1/4-20 x 1/4" Cup Point Set Screw S.S.
8-32 x 1/8" Nonmarring Flat Point Set Screw S.S.
10-24 X 1/2 Pan Head Torx Drive Type 23 Self Tapping Screw Zinc Plated
1/4-20 Square Nut
1/4-20 X 5/8 Socket Head Cap Screw S.S.
1/4 Washer S.S.
Jointing Washer Linkage
10-24 Hex Nut S.S.
TA Clamping Knob
Guard Mount
Guard Adjustment Shaft
Guard Guide Tube Mount
Guard Linear Adjustment Knob
Guard Locking Collar
Guard Height Adjustment Mount
Guard Height Adjustment Knob
Guard
1/4-20 x 1/2" Stainless Steel Low Profile SHCS
#10 O-Ring
Fence Clamping T-Nut
Fence Infeed T-Nut
Fence Outfeed T-Nut
1/4-20 X 5" Hex Head Cap Screw Zinc Plated
1/4-20 X 3" Hex Head Cap Screw Zinc Plated
10-24 X 3/4 Pan Head Torx Drive Machine Screw S.S.
Infeed Clamping Knob
1/4-28 X 1/4" Oval Point Set Screw S.S.
Guard Guide Tube
TA Clamping Knob Mount
TA Clamping Knob Retainer
Fence Clamping Knob
Outfeed Fence Body (Jointing)
Jointing Spindle
Jointing Washer Spacer
Jointing Indicator
Jointing Dial
Jointing Adjustment Knob
Jointing Nut
Jointing Knob Spacer
Infeed Scale Bar
Qty
1
1
1
1
2
6
20
2
2
2
2
2
2
1
2
2
16
6
6
6
1
4
2
1
1
1
1
1
1
2
1
1
2
2
1
1
2
2
2
2
2
1
2
2
2
1
2
2
1
2
2
2
2
1
