JessEm Tool Mast-R-Lift 02101 User Manual

Routers.
Hide thumbs


Advertisement

Mast
R

User Manual

Model #02101, 02102
Thank you for choosing this product from
JessEm Tool Company. We appreciate your
support and hope that our product serves you
well. This product is designed to provide
many years of reliable service provided it is
used as intended and taken care of.
This user manual will assist you in assembly
and general operation of this product. It is
not our intent to teach you about
woodworking. It is assumed that you are an
experienced woodworker with the basic skills
and experience necessary to use this product
safely. If after reading the following
instructions, if you are unsure or
uncomfortable about safely using this
product we urge you to seek additional
information through widely available
woodworking books or classes.
Suggested Router Bit Speeds
Bit Diameter
1" (25mm)
1-1/4" - 2" (30-50mm)
2-1/4" - 2-1/2" (55-65mm) 16,000 RPM
3" - 3-1/2" (75-90mm)
Lift
Max. Speed
24,000 RPM
18,000 RPM
12,000 RPM
124 Big Bay Point Road
Barrie, Ontario, L4N 9B4
Canada
866-272-7492 Toll Free
705-726-6145 Local Phone
705-726-6055 Fax
Email: jessem@jessem.com
Website: www.jessem.com
IMPORTANT!
Read and understand the contents of
this manual before assembly or
operation of this product.
As part of our Continuous Product
Improvement Policy, JessEm products are
always advancing in design and function.
Therefore there may be differences between
what is shown in our catalogs, website or at
retail display and what is sold at time of
purchase. We reserve the right to make
positive changes to our products at our
discretion.
CONTENTS:
1-Mast-R-Lift
1-Height Adjustment Handle
Also includes 1-Insert Ring, 1-Insert Ring
Wrench, 1-1/8" Hex Wrench, 1-Start Pin
TOOLS REQUIRED FOR ASSEMBLY:
5/16" Hex Wrench
TOOLS REQUIRED FOR ADJUSTMENT:
7/16" Wrench

Advertisement

Table of Contents

   Summary of Contents for JessEm Tool Mast-R-Lift 02101

  • Page 1: User Manual

    Email: jessem@jessem.com Website: www.jessem.com Thank you for choosing this product from IMPORTANT! JessEm Tool Company. We appreciate your Read and understand the contents of support and hope that our product serves you this manual before assembly or well. This product is designed to provide operation of this product.
  • Page 2 IMPORTANT SAFETY PRECAUTIONS INSTALLING THE ROUTER 1. Place the crank handle into the hex hole in Before operating any router read and the lift’s dial on the top plate. Crank the lift understand all safety instructions in the carriage up so that it just contacts the O-rings at owner’s manual that came with the router.
  • Page 3 INSTALLING THE ROUTER (cont’d) Rotate the router so that when the final installation is made all router controls will be positioned for convenient access. Then back the motor off approx. 1/16” from contacting the top plate and tighten the cap screw on the carriage assembly.
  • Page 4 JessEm Tool Company. We will repair or replace the product at our discretion and JessEm Tool will return shipment to you at no charge. WARRANTY LIMITATIONS This warranty does not cover:...
