HCC1000AHT, HCC1400AHT, HCC1000WHT, HCC1400WHT,
HMC1000AHT, HMC1400AHT, HMC1000WHT, HMC1400WHT,
HCE1000AHT, HCE1400AHT, HCE1000WHT, HCE1400WHT
HME1000AHT, HME1400AHT, HME1000WHT, HME1400WHT
(See model number confi gurator on page 2 for details.)
Order parts online
www.follettice.com
fi t most countertop dispensers manufactured by
Horizon
Horizon top-mount ice machines
Cornelius • Lancer • SerVend
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Ice Machine Installation Instructions
for Harmony
Top-mount Applications
208264
Stock Module Identification Plate
Module No.
Product
Service No.
self-contained
00159913R06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Horizon HCC1000WHT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Follett Horizon HCC1000WHT

  • Page 1 ™ Horizon Ice Machine Installation Instructions ™ for Harmony Top-mount Applications HCC1000AHT, HCC1400AHT, HCC1000WHT, HCC1400WHT, HMC1000AHT, HMC1400AHT, HMC1000WHT, HMC1400WHT, HCE1000AHT, HCE1400AHT, HCE1000WHT, HCE1400WHT HME1000AHT, HME1400AHT, HME1000WHT, HME1400WHT (See model number confi gurator on page 2 for details.) Order parts online www.follettice.com self-contained Horizon top-mount ice machines...
  • Page 2 Chewblet ® Ice Machine Model Number Configurations 1400 Icemaker Voltage Series Condenser Application Configuration MC Maestro™ C 208-230/60/1 (icemaking head) 400 up to A Air-cooled, self-contained V Vision™ S RIDE™ Self-contained only. 454 lbs Chewblet ® W Water-cooled, self-contained H Harmony™ (RIDE remote D 115/60/1 (icemaking head) (206kg)
  • Page 3 Read and complete the following 8 installation steps Unpack Site preparation Bin preparation Louvered docking assembly External connection Ice transport tube Internal connection Front cover HARMONY • TOP-MOUNT self-contained...
  • Page 4 Unpack Carefully unpack and inspect the contents of your Follett ice machine. Unpack ice machine ➊ ➋ ➌ ➍ 1/2" 1/2" ➎ ➏ HARMONY • TOP-MOUNT self-contained...
  • Page 5: Site Preparation

    Potable water supply • 10-70 psi (69-483kpa) • 45 to 90 F (7 to 32 C) • Follett recommends the use of an in-line water fi ltration system (#00130286) ➌ Condenser water supply for water-cooled systems • 10 psi min.; 150 psi max. (69kpa min.; 1034kpa max.) •...
  • Page 6: Dispenser Preparation

    Dispenser preparation Prepare the dispenser. Note: The instructions below only apply to 22" & 30" wide dispensers. 44" wide dispenser instructions may be found with the top kit. Top preparation – ALL Top preparation – ALL ➊ ➊ ➌ ➊ ➊...
  • Page 7 Agitation adjust. – CORNELIUS Top preparation – LANCER ➊ ➋ ➋ Cornelius models ED, DB, DF, IDC Lancer models only and Flavor Fusion ➊ • Remove protective tape ➋ Adjust the agitation timer located on the • Apply gaskets Cornelius PC board to 1 second on, 1 hour off.
  • Page 8 Agitation adjustments – LANCER FS SERIES Initialization Screen (Boot Up Only) Lancer FS-16 Ver. 0.200 ➊ Main Menu Sub-Catagory FS-16 Setup Brands Per Side Major/Minor V:1 L:2 R:1 FS-16 Setup Bonus Key Setup Config Bonus Key V:1 T:F M:S B:W FS-16 Setup Soda/Plain Water Cancel...
  • Page 9 3.10 Dispenser diverter plate installation – CORNELIUS ED, DF and DB SERIES storage bin gate mounting plate gate restrictor plate ice diverter (supplied) gasket ice chute flange extends into storage bin through gate opening apply food-grade silicone sealant to flat washer this surface to seal to bin gate 10-32 nut mounting plate...
  • Page 10 3.11 Restrictor plate adjustment – CORNELIUS IDC and FLAVOR FUSION ➋ adjust restrictor plate to fully open position ➊ Cornelius IDC and Flavor Fusion These dispensers require the adjustment of the ice restrictor plate. ➊ • Loosen four nuts on ice chute assembly ➋...
  • Page 11 Louvered docking assembly Install the louvered docking assembly. WARNING • Docking station must be secured in accordance with these instructions to ensure ice machine stability. • Ventilation openings in the louvered docking station should be clear of obstruction Louvered docking assembly •...
  • Page 12: Ice Transport Tube

    Ice transport tube Install the ice transport tube. Ice transport tube installation Hot Water 160 F (71 C) • Install supplied ice transport tube insulation ➊ • Heat end of transport tube in cup of 160 F (71 C) hot water to soften and spread with pliers before making connection to ease assembly ➋...
  • Page 13: External Connections

    External connections Connect utilities to louvered docking assembly. Air-cooled ice machines only Water-cooled ice machines only ➌ ➋ ➍ ➋ ➊ ➊ • Remove access panel if necessary • Remove access panel if necessary ➊ ➊. • Install drain line •...
  • Page 14: Internal Connections

    Internal connections Connect louvered docking assembly to ice machine. CAUTION • Plug must be accessible after fi nal installation. • H_E1400A/W 230/50/1 requires a 20A circuit (4.00 mm wire) Air-cooled ice machines – follow steps 7.1 through 7.4. Ice transport tube Potable water line ➊...
  • Page 15 Water-cooled ice machines – follow steps 7.5 through 7.10. Cooling lines Ice transport tube ➋ ➊ • Install ice machine cooling water lines to • Slide ice machine into louvered docking ➊ louvered docking assembly assembly • Insert ice transport tube into coupling and ➋...
  • Page 16 7.10 Power cord Power cord • Remove twist tie • Position plate into opening and secure with supplied screw • Carefully pass plug thru opening and plug into wall outlet HARMONY • TOP-MOUNT self-contained...
  • Page 17: Front Cover

    Front cover Install front cover to ice machine. Water-cooled ice machines only ➋ ➊ • Slide ice machine cover over machine ensuring that tabs on back of cover slip under louvers on back of louvered ➊ docking assembly • Insert and tighten two screws through cover and into louvered docking assembly ➋...
  • Page 18 Long tube run recommendations max. 2 ft (0,6m) 1/4" (6,4mm) 1' (0,3m) ➊ • Pitch ice transport tube to allow melt water to drain towards ice machine ➋ • Secure insulated ice transport tube at least every 2 ft (0,6m) to prevent dips or traps HARMONY •...
  • Page 19 HARMONY • TOP-MOUNT self-contained...
  • Page 20 Horizon, Maestro, Harmony, Ice Manager, SafeCLEAN, Sani-Sponge, RIDE and Vision are trademarks of Follett Corporation. Chewblet is a registered trademark of Follett Corporation, registered in the US. 801 Church Lane • Easton, PA 18040, USA 00159913R06 Toll free (877) 612-5086 • +1 (610) 252-7301 3/12 www.follettice.com...
