DeVilbiss IntelliPAP Standard DV51 Quick Start Manual

NOTE: Refer to instruction manual for more detailed instructions.
STEP 1
STEP 2
STEP 3
A
B
C
STEP 4
SETTING UP YOUR UNIT
Remove the IntelliPAP DV51,
the humidifier cradle, and the
blue water chamber from the
largest section of the carrying
case.
Remove the tubing and the
power cord from the zipper
pockets found on either side
of the carrying case.
Remove blue water chamber
from humidifier cradle (A).
Tilt upright so the front of
the chamber is pointing
toward the ground (B). Pour
water into the water
chamber, which is marked
with maximum capacity
water lines (C). It is
recommended that you use
distilled water so there is not
mineral deposit build up on
the inside of the humidifier.
Slide the water chamber
back into the humidifier
cradle.
IntellIPAP® stAndArd dv51
QUICKstArt GUIde
STEP 5
A
B
STEP 6
STEP 7
STEP 8
Place IntelliPAP on top of
heated humidifer cradle (A).
Slide the blue water chamber
out slightly before attached
IntelliPAP . Be sure to align the
front corners first so the
IntelliPAP and humidifer lock
into place (you'll hear a click,
indicating it's in the proper
position). All sides should be
flush (B).
Plug power cord into the
back of IntelliPAP .
Attach tubing to air supply
port on the back of the
humidifier. Push rubber seal
downward until it meets the
plastic. NOTE: The rubber
air supply port plug should be
sealing the port on the back
of the CPAP , not the port on
the bottom of the unit.
Attach free end of tubing to
interface/mask port.
