Rice Lake 520 Installation Manual page 56

Command
SETPOINT Setpoint number
KIND Setpoint kind
VALUE Setpoint value
PSHTARE Push tare
PSHPRINT Push print
PSHACCM Push accumulate
TRIP Trip
BANDVAL Band value
HYSTER Hysteresis
ALARM Alarm
PREACT Preact
PREVAL Preact value
PREADJ
PRESTAB
PREBAND
PRECOUNT
BATCH Batch enable
BATSTART Batch step enable
BATPAUSE Batch step pause
BATRESET Batch step reset
BATSTATUS Batch status
NAME Setpoint name number
ACCESS Setpoint access
DIGOUT Digital output
RELNUM Relative setpoint numer
START Starting setpoint
END Ending setpoint
BATCHNG Batching mode
Command
GFMT Gross demand print format string
NFMT Net demand print format string
CFMT Count format string
SPFMT Setpoint print format string
EDPFMT EDP demand print format string
HDRFMT Ticket header format string
STRMFMT Custom stream format string
Description
1–8
OFF, GROSSSP, NETSP, +RELSP, –RELSP, %RELSP, PAUSE,
DELAY, WAITSS, COUNTER, AUTOJOG, COZ, INMOTON,
INRANGE, –GROSS, –NET, BATCHPR, TIMER, CONCUR
number
OFF, ON
OFF, ON, WAITSS
OFF, ON, ONQUIET
HIGHER, LOWER, INBAND, OUTBAND
number
number
OFF, ON
OFF, ON, LEARN, FLOW
number
1-100%
0-65535
number
1-65335
OFF, ON
See Section 12.0 on page 59 for detailed information
NONE, 1–8
OFF, ON, HIDE
NONE, 1–4
1–8
1–8
1–8
OFF, AUTO, MANUAL
Table 10-8. SETPNTS EDP Commands
Description
See Section 11.2 on page 57 for detailed information
Table 10-9. PFORMT EDP Commands
Values
Values
EDP Commands 51
