Command
PRI.DECPNT Primary units decimal position
PRI.DSPDIV Primary units display divisions
PRI.UNITS Primary units
SEC.DECPNT Secondary units decimal
position
SEC.DSPDIV Secondary units display divisions 1D, 2D, 5D
SEC.UNITS Secondary units
SEC.MULT Secondary units multiplier
DECFMT Decimal format
DSPRATE Display rate
Command
WVAL Test weight value
WLIN.F1–WLIN.F5 Actual raw count value for linearization points 1–5
WLIN.V1–WLIN.V5 Test weight value for linearization points 1–5
WLIN.C1–WLIN.C5 Calibrate linearization points 1–5
WLIN.M1–WLIN.M5 Millivolt value for linearization points 1–5
WLIN.W1–WLIN.W5 Working calibration values
LC.CD Set deadload coefficient
LC.CW Set span coefficient
WK.CD Working deadload coefficient
WK.CW Working span coefficient
MV.CD Millivolt calibration value
MV.CW Millivolt span calibration value
Command
EDP.BAUD EDP port baud rate
EDP.BITS EDP port data bits/parity
EDP.TERMIN EDP port termination character
EDP.EOLDLY EDP port end-of-line delay
EDP.HANDSHK EDP port handshaking
EDP.ADDRESS EDP port RS-485 address
EDP.STREAM EDP port streaming
EDP.FORMAT EDP port stream format
PRN.BAUD Printer port baud rate
PRN.BITS Printer port data bits/parity
48 520 Installation Manual
Description
8.888888, 88.88888, 888.8888, 8888.888, 88888.88, 888888.8,
8888888, 8888880, 8888800
1D, 2D, 5D
LB, KG, G, OZ, TN, T, GN, LT, NONE
8.888888, 88.88888, 888.8888, 8888.888, 88888.88, 888888.8,
8888888, 8888880, 8888800
LB, KG, G, OZ, TN, T, GN, LT, NONE
0.00000–99999.99
DOT, COMMA
250MS, 500MS, 750MS, 1SEC, 1500MS, 2SEC, 2500MS, 3SEC,
4SEC, 6SEC, 8SEC
Table 10-4. FORMAT EDP Commands
Description
Table 10-5. CALIBR EDP Commands
Description
Table 10-6. SERIAL EDP Commands
300, 600, 1200, 2400, 4800, 9600, 19200
8NONE, 7EVEN, 7ODD
CR/LF, CR
0–255 (0.1-second intervals)
OFF, ON
0, 01–255
OFF, LFT, IND
DEFAULT8, CUSTOM, BUS FMT, DEFAULT7
300, 600, 1200, 2400, 4800, 9600, 19200
8NONE, 7EVEN, 7ODD
Values
Values
test_weight_value
—
test_weight_value
—
test_weight_value
—
value
value
—
—
—
—
Values
