8.0

Peak Hold Mode

The peak hold function is used to determine, display,
and print the greatest net weight read during a
weighing cycle.
A weighing cycle ends when the print command is
given, or when the peak net weight is manually
ZERO
cleared by the key. Peak hold tracks only net
weight and operates independently of the display. For
example, if the indicator is displaying gross weight,
but AUTO peak hold is active, the display will remain
in gross, but the net peak weight will be automatically
printed when standstill is achieved at net zero.
Peak hold function is enabled in the setup mode.
Parameter settings are found under the PK HOLD
submenu, in first level program menu.
Normal (Positive Peak, Manual Reset)
This is the basic peak hold function in which a weight
is applied to a scale and the greatest net weight value
is held in memory until the weight is removed from
the scale, and either the
pressed. If the display is in gross mode, the peak net
weight can be displayed by toggling to the net mode
G/N
with the key.
NOTE: A tare weight can be used with peak hold. At
the tare value, the highest peak hold is 0 net. Tare is
cleared by returning to gross zero and pressing the
key.
TARE
Bi-Dir (Bi-Directional Peak, Manual Reset)
This is the same as NORMAL parameter setting
(above), except that the peak can either be a positive
or negative number, determined by the absolute
weight value. This means that if a positive peak is
displayed, a negative weight value of greater absolute
value can update the peak information in the same
cycle. As above, the peak cycle is reset by pressing the
ZERO
or key after the weight has been
PRINT
removed.
44 520 Installation Manual
ZERO
or PRINT key is
Auto (Positive Peak, Auto Print, Auto Reset)
This is the same as NORMAL parameter setting
(above), except that automatic print occurs when the
scale load is reduced to 0 ± 10 display divisions and
the scale achieves standstill. Following the print
command, the peak value is cleared and reset
automatically. As in the above two modes, the peak
hold value can also be cleared by the
PRINT
a manual press of the
The digital display can be set to display gross weight
information data using the
hold function cycles.
ZERO
key, or by
key.
G/N
mode key during peak
