Installing the Pillars, Crossbars, and Rear Kick Plate/Toe Cap
6a
Attach the left and right rear kick plates (left 700-43101-xx, right 700-43099-xx).
the rear side kick plates over the notch in the rear center kick plate.
kick plate) into the slot in the frame.
b. Stud
Slot
b. Place the studs (one for each
700-43101-xx
a. Pin
Notch
a. Hook the pin on
700-43099-xx
Page 4-7
