Installing the Lower and Upper Display Frames
4
Set the frame position from the rear wall. The distance should be a minimum of 150mm (6 inches) from
the back of the frame to the wall. Measure two positions (left side and right side of the center frame) to
ensure that the frame is parallel to the rear wall.
Rear Wall
Minimum 6"
(150 mm)
