- Page 1 UniGuard Technology Limited Magnetic GPS Tracker User Manual UM666 Attention: Charge is forbidden. 24Hrs per locate: 3 Years (Default) www.uniguardgps.com...
- Page 2 UniGuard Technology Limited 1 GPS Tracking System Introduction Portable GPS Tracker UM660 integrates GPS and GSM functions, which could send vehicle location and status to mobile and Internet. It utilizes GPS and LBS double locating. Its advantage is that the builtin battery can last 2 years at reporting interval every 24hrs.
-
Page 3: Product Description
UniGuard Technology Limited 2 Product Description 2.1 Specification Content Specifications Dimensions 66 x 52 x 36mm Weight 105g Network GSM/GPRS Band 850/900/1800/1900Mhz GPS chip UBLOX-7 GSM Module MTK6260D GPS sensitivity -159dBm GPS accuracy Time to First Fix Cold status 45-120s... - Page 4 UniGuard Technology Limited 2.2 Picture and main functions: 3 Commands Function SMS command Set IP and Port adminip123456 104.243.132.242 8000 Set Domain and Port adminip123456 www.gpspos.net 8000 Set APN apn123456 aaa bbb ccc Set Working Mode:1 2 3 RTC123456 2...
-
Page 5: Web Tracking
UniGuard Technology Limited Send command: RTC123456 1 【Mode 2-GPS Mode】 ：every 24 hours wakeup 1 time to send GPS data Send command: RTC123456 2 【Mode 3-Real time Mode】 ：every 60seconds time interval to send GPS data Send command: RTC123456 3 Attention: Attention: Don’t switch to Mode 3 randomly otherwise device... - Page 6 UniGuard Technology Limited UM666 Testing Guide Before installing in vehicle, make sure all settings are ready to configure. 1) Device defaults 24 hours time interval LBS mode【Mode 1】 2) If need to switch to 24 hours time interval GPS mode【Mode 2】 ， steps as...
