Cub Cadet Pro2B+ 21120902 Operator's Manual

Pro-x power assist twin bag
Hide thumbs
Table of Contents

Advertisement

Quick Links

PRO-X
DESIGNED
POWER ASSIST TWIN BAG
TO FIT:
MODEL YEAR:
Series:
PRO Z 100 L & S
2016-NEWER
- 48",54" & 60" DECKS
COLLECTION SYSTEM
FOR SERIAL RANGE:
59A30046150
2E226XP0001
MODEL #
& UP
ALTERNATE
21120902
MODEL #
OPERATOR'S MANUAL
ASSEMBLY
OPERATION
MAINTENANCE
MANUAL PART#: Q0506
Rev 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro2B+ 21120902 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cub Cadet Pro2B+ 21120902

Summary of Contents for Cub Cadet Pro2B+ 21120902

  • Page 1 PRO-X DESIGNED POWER ASSIST TWIN BAG TO FIT: MODEL YEAR: Series: PRO Z 100 L & S 2016-NEWER - 48”,54” & 60” DECKS COLLECTION SYSTEM FOR SERIAL RANGE: 59A30046150 2E226XP0001 MODEL # & UP ALTERNATE 21120902 MODEL # OPERATOR’S MANUAL ASSEMBLY OPERATION MAINTENANCE...

  • Page 2: Table Of Contents

    RESIDENTIAL BAGGING SYSTEM TABLE OF CONTENTS SECTION PAGE SECTION PAGE Safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 2-14 Lower Hose To Blower Cone Installation- - - - - - 13 Safety Alert Symbols - - - - - - - - - - - - - - - - - - - - - - 3 2-15 Lower Hose To Boot Installation - - - - - - - - - - - 13...

  • Page 3: Safety

    SAFETY WARNING! NEVER operate the mower unless the discharge guard and either the deflector assembly or the vacuum collector adapter are fastened securely in place. WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower blades and the blower impeller have stopped rotating.

  • Page 4: Warranty

    PECO LIMITED WARRANTY FOR NEW PRODUCTS A. WHAT IS UNDER WARRANTY? PECO extends the following warranties to the original purchaser of each new PECO consumer product subject to the following limitations. 1. PRODUCT WARRANTY: Any part of any consumer product, which is defective in material or workmanship as delivered to the purchaser will be repaired or replaced, as PECO elects, without charge for parts or labor, if the defect appears within 12 months from the date of delivery of the product to the original purchaser.

  • Page 5: Introduction

    Section I - INTRODUCTION & 2-1 Preparation Of Mower From the underside of the engine, disconnect the wiring DESCRIPTION harness attached to the electric clutch. Remove the bolt and electric clutch from the mower. Refer to Figure 2-1a. 1-1 Introduction Remove the D-drive spacer using an arbor press or Your grass collection system has been designed to give equivalent.

  • Page 6: Mount Arm Preparation And Installation

    2-2 Mount Arm Preparation and Installation Remove the (3) 1/2”-13 x 1-1/4” existing HHCS, (3) 1/2” washers and (3) 1/2”-13 Ny-Flange locknuts from the right- rear of the mower and save the 1/2” Flat Washers for the next step. Next, loosen bolts on opposite side of mower for rear bumper alignment in the next step.

  • Page 7: Pto Drive Assembly

    2-3 PTO Drive Assembly Once the Mount Arm Assembly P#(A2063_01) is installed and secured to the mower, assemble the Drive Assembly P#(A2061_01), Belt Guard Assembly P#(A2069_02), and the Idler Mount Assembly P#(A2067_02). First, attach the Belt Guard Assembly P#(A2069_02) to the Drive Assembly P#(A2061_01) using (2) 1/4”-20 x 5/8”...

  • Page 8: Pto Drive Assembly

    2-3 PTO Drive Assembly (Continued) Attach the Idler Mount Assembly P#(A2067_02) to the Drive Assembly using (1) 3/8”-16 x 1” HHCS (A) P#(K1191), (1) 3/8”-16 x 1” Carriage Bolt (B) P#(K1182) and (2) 3/8”-16 Ny-Flange Lock Nuts P#(K2038). Refer to Figure 2-3b. Leave Bolts Loose (Note: Orientation of bolts A &...

  • Page 9: Drive Assembly And Belt Installation

    2-4 Drive Assembly and Belt Installation (Note: It is recommended that someone assist during this step.) Insert the Drive Assembly into the receiver tube on the Mount Arm Assembly until the Knob Plunger Pin engages. Once in place, turn Lock Handle clockwise until tight. Next, feed the AK83 Belt P#(M0315) between the Belt Guard and the Idler Mount Assembly.

  • Page 10: Lower Mount Tube Installation

    2-5 Lower Mount Tube Installation Figure 2-7 Clevis Secure the (2) lower mount tubes P#(B0752) to the rear Hair Pin frame using (2) 5/16”-18 u-bolts P#(K1098) and (4) Nylon Clip Flange 5/16”-18 nylon flange locknuts P#(K2516) PER TUBE. Locknut Refer to Figure 2-5. Note: Bottom of Tubes should rest Top Assembly on the top edge of the Trailer Hitch Plate.

  • Page 11: Blower Cone Installation

    2-10 Blower Cone Installation Thread (1) 5/16”-18 jam nut P#(K0120) onto each end of (2) 5/16”-18 x 2-1/2” HHCS P#(K0125) as shown in Figure 2-10a. Figure 2-10a Thread (1) Jam Nut Onto Each 5/16”-18 Bolt Now partially thread (1) bolt into each of the two threaded bosses located on the blower housing. Place 8”...

  • Page 12: Boot To Mower Deck Installation

    According to deck size, align marked holes and Boot holes. 2-11 Boot To Mower Deck Installation Secure the boot mounting assembly P#(A2045) to the aluminum boot P#(E0028A) using (2) 3/8”-16 x 1” carriage NOTE: The boot kit assembly is designed to fit the 48”, bolts P#(K1182) and (2) 3/8”-16 nylon flange locknuts 54”...

  • Page 13: Length Of Hose Adjustment

    2-12 Length Of Hose Adjustment 2-14 Lower Hose To Blower Cone Installation The hoses in steps 2-13 and 2-14 must be cut to fit your machine. Follow steps 2-13 and 2-14. do not cut the Slide a clamp P#(J0080) over both ends of the lower hoses until you have tried to fit them on your machine.

  • Page 14: Installation/Removal Of Collection Bags

    2-16 Installation/Removal Of Figure 16-c Plastic Top Figure 2-19c Collection Bags IMPORTANT! To prevent bag wear, install (1) black rubber end cap P#(F0010), as shown in Figure 2-16a, on each bag ring after rotating bag 360. Bag Ring Figure 2-16a Black Rubber Connector Fasten Draw-...

  • Page 15: Weight Kit Installation

    2-17 Weight Kit Installation WARNING Note: Installing a weight kit is mandatory for safe operation of the collection — system. To Prevent Serious Injury- When installing the weight bar, you should have another person to help — Weight Kit Must Be Installed position the weight.
  • Page 16 2-18 Safety Interlock Wiring Harness Installation Note: orientation Figure2-18a P#(P0073) P#(P0270)

  • Page 17: Safety Interlock Harness Installation

    2-18 Safety Interlock Harness Installation (Continued) Route the PTO connector (C) around front side of Collection System May Require Dealer Installation! engine, between the ROPS and gas tank and Before installing, please verify the presence of an auxiliary 5- through the opening in the rear bumper connecting way female connector in the mower’s electrical harness.

  • Page 18: Safety Interlock Harness Installation

    2-18 Safety Interlock Harness Installation (Continued) Once the safety interlock wiring harness is installed use the connectors provided to secure in place. Insert the rosebud clips in the 1/4” holes on the engine shield as shown. Zip straps are also included to aid in securing the harness.
  • Page 19 2-18 Safety Interlock Harness Installation (Continued) Wiring Schematic...

  • Page 20: Impeller Blade Removal/Replacement

    2-19 Impeller Blade Removal/Replacement To Remove: First remove the 5/16”-24 x 1” HHCS P#(K0428) (#1), taper lock bushing washer P#(K0284) (#3), (2) 5/16 Flat Wahers P#(K0042) and spacer bushing P#(S0159) (#4) from the taper-lock bushing P#(S0157) (#5). See Figure 2-19. Next remove the (2) 1/4”-20 x 1” HHCS (#2) and place them into the threaded holes of the taper-lock bushing (#5).

  • Page 21: Even Bag Fill Adjustment

    2-20 Even Bag Fill Adjustment Flap Can Be Adjusted Up/Down Depending On Mowing Conditions. Adjust Flap Up To Allow More Dense Material To Reach Left Bag. Adjust Flap Down To Allow Less Dense Material To Reach The Right Bag. Once Adjusted Properly, Both Bags Should Fill Evenly, But May Require Further Adjusting When Mowing Conditions Change.
  • Page 22 A2063_01 Mount Arm Assembly Item # Part # Desc. Qty. A2033_01 Mount Arm Sub-Assy J0013 Nylon Flat Washer 1/2" x .750" OD Grade 6/6 K0027 Flat Washer 1/2" / .787 OD x .512 ID x .090 T J0020 Knob Plunger Pin 1/2"-13 J0009 Adjustable Handle 1/2"-13 x .59 Male...
  • Page 23 A2045 Boot Mounting Assembly Item # Part # Desc. Qty. A2044 Deck Plate Assy A2043 Boot Plate Assy K1429 3/8"-16 x 6" HHCS GR5 K0042 Flat Washer 5/16" / .875 OD x .380 ID x .075 T K2038 Ny-Flange Lock Nut 3/8"-16 J0017_1 Torsion Spring K1146...
  • Page 24 A2092 Idler Arm Assembly Item # Part # Desc. Qty. A2070_01 Idler Arm Weldment K1467 Flat Washer M6 x 12mm OD J0801 1/4"-28 Zirc Fitting A2067_02 Idler Mount Assembly Item # Part # Desc. Qty. B0958_02 Idler Mnt Pl K2038 Ny-Flange Lock Nut 3/8"-16 K1463 Flat Washer .720 ID x 1.500 OD x .250 T...
  • Page 25 A2058 Gearbox Sub-Assembly Item # Part # Desc. Qty. M0002 Gearbox K0428 HHCS 5/16"-24 x 1" GR8 K0043 Lock Washer 5/16" N0002 Pillow Block Bearing 7/8" K0035 Set Screw 5/16"-18 x 1/4" Cup Point J0272 Woodruff Key #9 A2048 Clutch Flange Assy...
  • Page 26 A2059_01 Clutch Sub-Assembly Item # Part # Desc. Qty. (Ogura 110 Ft-Lb Clutch/Brake) M0001 Electric Clutch S0007 Clutch Shaft K0278 Double Indented Washer 7/16" / 1.375 OD x .440 ID x .179 T K0140 Lock Washer 7/16" / High-Collar Helical Spring K0359 HHCS / 7/16"-20 x 4.00"...
  • Page 27 A2057_01 Drive Assembly Exploded Parts View Item # Part # Desc. Qty. K0048 Lock Washer 3/8" K0343 HHCS 3/8"-16 x 7/8" GR8 A2059_01 Clutch Sub-Assy (See Page 26) A2058 Gearbox Sub-Assy (See Page 25)
  • Page 28 A2060_01 Mounted Drive Assembly...
  • Page 29 A2039_01 Base Drive Assembly Item # Part # Desc. Qty. B0938 Drive Guard A2032 Drive Arm Assy A2035_01 Housing Mnt Assy B0942_01 Anti-Rotation Brkt K1153 HHCS 5/16"-18 x 3/4" K0043 Lock Washer 5/16" K0353 HWHTCS 1/4"-20 x 1/2" K1154 HHCS 5/16"-18 x 1" K2516 Ny-Flange Lock Nut 5/16"-18 A2060_01 Mounted Drive Assy...
  • Page 30 A2061_01 Drive Assembly / 4 Blade Impeller Item # Part # Desc. Qty. A0645 4-Blade Impeller Assy K0284 Double Indented Washer 3/8" / 1.375 OD x .380 ID x .179 T K1465 HHCS 5/16"-24 x 1-1/2" GR8 K1225 HHCS 1/4"-20 X 1" GR8 S0159 Spacer Bushing .938 OD x .325 ID x .375 T K0044...
  • Page 31 A2110 Top Assembly Exploded Parts View Item # Part # Desc. Qty. V2000 Pro 2 Bagger Top / Gen. 2 V2001 Screen J4009 Short Rubber Strap w/ S-Hook K1030 1/4"-20 x 1-1/4" Carriage Bolt K0037 Flat Washer / 1/4" (.75 OD x .312 ID x .060 T) K1128 1/4"-20 Nyloc Nut K0062...

  • Page 33: Safety Decals

    To promote safe operation, New PECO, Inc. supplies safety decals on all products manufactured. Damage can occur to safety decals either through shipment, use or reconditioning. Contact your local Service Center for replacement decals. Part# R0023 Cub Cadet Logo DANGER...

  • Page 34: Operating Instructions

    SECTION III 3-3 Disengagement Of The PTO OPERATING INSTRUCTIONS Assembly A. To disengage the PTO assembly, move switch to the 3-1 General Safety off position. Only qualified people familiar with this operator’s manual WARNING: The PTO assembly blades will continue to and the mower’s operator’s manual should operate this spin.

  • Page 35: Lubrication

    3. Make sure all shields are in place and in good Blower Assembly: condition. Repair or replace any missing or damaged 1. Every 100 hours grease idler arm grease fitting with white lithium grease. shields. 4. Perform lubrication per paragraph 4-2. SECTION V 5.

  • Page 37: Troubleshooting

    Troubleshooting Collection System Performance Problem Possible Cause Corrective Action — Install new cutting blade — Cutting blades are bent or unbalanced — Loose blower pulley or pulley Abnormal Vibration — Tighten the pulley assembly — Impeller blade out of balance —...
  • Page 38 Cub Cadet LLC P.O. Box 361131 Cleveland, Ohio 44136-0019 Phone: 1-877-282-8684 MTD Products Limited Kitchener, ON N2G 4J1 1-800-668-1238...
