Cub Cadet TANK Series Operator's Manual
  1. Manuals
  2. Brands
  3. Cub Cadet Manuals
  4. Lawn Mower Accessories
  5. TANK Series
  6. Operator's manual

Cub Cadet TANK Series Operator's Manual

Pto driven-grass collection system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL YEAR:
2014-2015
DESIGNED
TO FIT:
COLLECTION SYSTEM
MODEL #
COLLECTION SYSTEM
OF ADDED WEIGHT KIT P# 59A30037150 (A1149) FOR SAFE OPERATION!
MANUAL PART#: Q0466
TANK
SERIES
59A30042150
*LZ MODELS:
COLLECTION SYSTEM REQUIRES INSTALLATION
OPERATOR'S MANUAL
ASSEMBLY
OPERATION
COLLECTION SYSTEM
LZ
SZ
- 54" & 60"
- 54" & 60"
DECKS
DECKS
ALTERNATE
21621216
MODEL #
MAINTENANCE
PTO DRIVEN -
GRASS
Tank LZ Models:
53AI2PTC050
53BI2PTD050
53YI2PTC050
53YI2PTD050
53BH2PTD330
Tank SZ Models:
53AI2PUC050
53BI2PUD050
53YI2PUC050
53YI2PUD050
53RE2PUD050
53AI2PUD330
REV: 4 - June 18 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TANK Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cub Cadet TANK Series

Summary of Contents for Cub Cadet TANK Series

  • Page 1 PTO DRIVEN - GRASS MODEL YEAR: 2014-2015 COLLECTION SYSTEM TANK DESIGNED TO FIT: - 54” & 60” SERIES - 54” & 60” DECKS DECKS 59A30042150 COLLECTION SYSTEM MODEL # COLLECTION SYSTEM ALTERNATE 21621216 MODEL # Tank LZ Models: 53AI2PTC050 53BI2PTD050 53YI2PTC050 53YI2PTD050 53BH2PTD330...

  • Page 2: Table Of Contents

    PECO GRASS COLLECTION SYSTEM TABLE OF CONTENTS SECTION PAGE SECTION PAGE Safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 2-15 Length Of Hose Adjustment - - - - - - - - - - - - - - 16 Safety Alert Symbols - - - - - - - - - - - - - - - - - - - - - - 3 2-16 Upper Hose Installation - - - - - - - - - - - - - - - - 16...

  • Page 3: Safety Alert Symbols

    SAFETY WARNING! NEVER operate the mower unless the discharge guard and either the deflector assembly or the vacuum collector adapter are fastened securely in place. WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower blades and the blower impeller have stopped rotating.

  • Page 4: Warranty

    PECO LIMITED WARRANTY FOR NEW PRODUCTS A. WHAT IS UNDER WARRANTY? PECO extends the following warranties to the original purchaser of each new PECO consumer product subject to the following limitations. 1. PRODUCT WARRANTY: Any part of any consumer product, which is defective in material or workmanship as delivered to the purchaser will be repaired or replaced, as PECO elects, without charge for parts or labor, if the defect appears within 12 months from the date of delivery of the product to the original purchaser.

  • Page 5: Introduction And Description

    Requires installation of additional weight kit 59A30037150 (A1149) for — safe operation! SZ models only require the included weight kit (A1213). Contact your Cub Cadet dealer to order weight kit 59A30037150 (A1149). Tank LZ Models w/ 48” Deck: Requires installation of included weight kit —...

  • Page 6: Installation For Use

    Engine Pulley NOTE: The mower deck PTO belt must be removed Bushing from the electric clutch before continuing with the installation. Refer to your Cub Cadet mower owner’s Pulley manual for instructions on PTO belt removal. Clamp Washer From the underside of the engine, disconnect the wiring harness attached to the electric clutch.

  • Page 7: Pto Mount Plate Assembly Installation

    2-2 PTO Mount Plate Assembly Installation Secure the PTO mount plate assembly P#(A1108) to the chassis of the mower using (4) 3/8”-16 x 1” carriage bolts P#(K1182) and (4) 3/8-16 nylon flange locknuts P#(K2038). Leave the hardware loose until the lower mount assembly is installed in the next section. Refer to Figure 2-2.

  • Page 8: Pto Assembly Installation

    2-4 PTO Assembly Installation Insert the PTO assembly P#(A1821) into the slots on the PTO mount plate assembly. Secure the PTO assembly with (1) mount pin P#(B0274) and (1) hair pin clip P#(K0086). Remove the belt guard P#(B0679) and hardware in preparation for the belt installation.

  • Page 9: Drive Belt Installation And Adjustment

    Connect the drive belt A59K P#(M0254) from the engine 2-5 Drive Belt Installation and pulley to the lower gear box pulley (Figure 2-5d). Adjustment Figure 2-5d Loosen the (4) bolts P#(K1191), (2) on each side, that Connect Belt secure the gear box assembly to the PTO assembly To Both Pulleys P#(A1803) (Figure 2-5a and 2-5b).

  • Page 10: Cam Assembly Adjustment

    2-6 Cam Assembly Adjustment 2-7 Blower Cone Installation The cam assembly P#(A0422), which controls the A30K Thread (1) 5/16”-18 jam nut P#(K0120) onto each end of blower belt P#(M0250) tension, comes from the factory (2) 5/16”-18 x 2-1/2” HHCS P#(K0125) as shown in pre-adjusted.

  • Page 11: Safety Interlock Harness Installation

    P#(P0208) Installation Safety Interlock Harness To obtain access to the mower’s interlock switch, lift the operator’s seat on the mower as shown in Figure 2-8a. Refer to your Cub Cadet operator’s manual for reference. Safety Interlock Connect ROPS Figure 2-8a Switch Location Mower’s...

  • Page 12: Lower Main Frame Leg Installation

    2-10 Main Frame Assembly Installation 2-9 Lower Main Frame Leg Installation Lift the main frame assembly P#(A1192) into position and Secure (1) lower main frame leg P#(B0822) to the lower secure to the lower main frame legs using (4) 3/8”-16 x 1” main frame bracket using (2) 3/8”-16 x 1”...

  • Page 13: Lift Handle Installation

    2-11 Lift Handle Installation Fasten the ball joint P#(K1442) to the end of the latch NOTE: Before continuing the lift handle installation, rod P#(A0620). Tighten the ball joint to approximately have someone assist you in turning the grass container half way down the threads on the latch rod. Attach the upside down.

  • Page 14: Aluminum Grass Container Installation

    2-12 Aluminum Grass Container Installation NOTE: It is recommended that (3) people assist in mounting the container. With three people available, two Figure 2-12b can lower the container onto the frame while the third person inserts the pivot pins P#(K0172) through the holes.

  • Page 15: Boot To Mower Deck Installation

    2-14 Boot To Mower Deck Installation Secure the boot plate assembly P#(A1961) to the NOTE: The boot kit assembly is designed to fit the 48”, aluminum boot P#(E0026) using (2) 3/8”-16 x 1” carriage 54” and 60” deck. To ensure a snug fit between the boot bolts P#(K1182) and (2) 3/8”-16 nylon flange locknuts and the mower deck, follow the instructions in this step P#(K2038).

  • Page 16: Length Of Hose Adjustment

    2-15 Length Of Hose Adjustment 2-17 Lower Hose To Blower Cone The hoses in steps 2-16 and 2-17 must be cut to fit your Installation machine. Follow steps 2-16 and 2-17. Do not cut the Slide a pre-assembled hose clamp P#(J0080) over both hoses until you have tried to fit them on your machine.

  • Page 17: Impeller Blade Removal/Replacement

    2-19 Impeller Blade Removal/Replacement Tips on removing impeller blade; To gain impeller blade (#1) access, first remove the 1 - Try carefully hitting the base of the impeller blade blower cone (#2) from the blower housing, located on (#1), between each vein (#12), with a rubber mallet to the PTO assembly P#(A1821), by removing two blower loosen the taper-lock bushing hold.
  • Page 18 2-20 Included Weight Kit Installation Please Note: The images below may not fully represent your mower as some parts have been Installation Instructions For All Tank SZ Models: removed/hidden for visual clarity during installation. Refer to Figure 2-20a & 2-20b. —...

  • Page 19: Included Weight Kit Installation

    2-21 Additional Weight Kit Installation Figure 2-21c Installation Instructions For All Tank LZ Models: Installing the additional weight kit 59A30037150 (A1149) is mandatory for safe operation of the collection system. SZ models only require the included weight kit (A1213). Completely thread (2) 3/8”-16 flange nuts P#(K1215) onto (1) 3/8”-16 U-bolt P#(K0407).

  • Page 20: Exploded Part Views And Assemblies

    A1933 ALUMINUM GRASS CONTAINER EXPLODED VIEW...
  • Page 21 A1841_01 PTO Arm Assembly...
  • Page 22 A1941_01 PTO Base Assembly Exploded Parts View...
  • Page 23 A1941_01 PTO Base Assembly Exploded Parts List...
  • Page 24 A1623 PTO Assembly w/ Pulley Guard Exploded View Parts List...
  • Page 25 A1821 PTO Assembly w/ Heat Guard Exploded View Parts List...

  • Page 27: Wiring Diagram

    Wiring Diagram P0208 Safety Interlock Wiring Harness...

  • Page 28: Operating Instructions

    SECTION III OPERATING INSTRUCTIONS General Safety Disengagement Of The PTO Assembly Only qualified people familiar with this operator’s manual A. To disengage the PTO assembly, rotate the and the mower’s operator’s manual should operate this engagement handle towards the mower. machine.

  • Page 29: Lubrication

    3. Make sure all shields are in place and in good 4-2 Lubrication condition. Repair or replace any missing or damaged shields. Gearbox: NOTE: The gearbox is filled with 6.0 oz. of Mobilube 4. Perform lubrication per instructions. HD Plus 80W-90 oil and permanently sealed. There is no need for scheduled lubrication.

  • Page 30: Safety Decals

    Part #: R1049 Part #: R1069 Part #: R1055 Part #: R1057 Red Reflector Label Part #: R4037 Part #: R1054 Part #:R4015 Part #:R1083 Part #: R1065 Part #: R1052 Part #: R0006 - Cub Cadet Label Part #:R1051 Part #:R4008...
  • Page 32 Cub Cadet LLC P.O. Box 361131 Cleveland, Ohio 44136-0019 Phone: 1-877-282-8684 MTD Products Limited Kitchener, ON N2G 4J1 1-800-668-1238...

This manual is also suitable for:
