C-SMART·l Pro
8.5
Calibration
This function is to decrease fluctuation in the rotation speed of the motor
handpiece and the difference in torque by the contra angle.
Calibration is recommended when using a new/other contra angle or after
an extended period of operation, as the running properties can change with
usage, cleaning and sterilization.
The calibration steps as follows:
·Turn the power on.
; .tit
• Press the MODE key for 2 seconds (A) to enter setting interface;
• Press Up or Down key to select calibration (B);
·Press the SET key to enter the calibration state:
• The screen will be prompted to insert the motor handpice (Fig.37);
• During the calibration process the display will read (Fig.38):
0
0
Fig. 37 Insert the motor handpice
·The motor handpiece begins to rotate: leave it as it is until it stops.
·When the calibration process is completed,the rotation stops and the
display reads:
·Then, the display returns to its originalstate.
Uaar Manual
0
SETUP
A
Engllah
ld. .,.MII"' ·
A .,...- . ·
ON
ON •
,. ' i tt: lLE E DdiiiJt!Mt.
: T torvw
8 =torNWI,.fMIGIIJMtlll'll
B
_,r:::-1
e
.
-
0
Fig. 38 Cerebration state
b. Removing
Sliding it in the direction of the socket and then removed with contra-angle,
Otherwise it will be damaged.
.&.
CAUTIONS
•
When inserting and removing, please do not shake, so as not to damage
•
the plug.
7.3.4 Inserting and Removing the Fila
a. File insertion
• Insert the file into the chuck until it stops.
• Lightly turn the file until it engages with the latch mechanism. Push
inwards to click.
b. File removal
Press the push-key and pull out the file.
.&.
CAUTIONS
• When attaching and detaching the file, turn the power off beforehand.
• After the file is locked in place, lightly pull out the file to make sure the file
is locked.
• Always clean the shank of the file to be installed.Allowing dirt to enter the
chuck could cause deterioration of chucking force.
C-SMART·IPro Uoar Manual
Fig.4 Fig.5
