DEMA 607DM-BM Installation Instructions

I.

PARTS:

A. Fill Station Assembly
B. 1 pc. Priming ring
C. 1 pc. Outlet Tubing, 12' long
D. 1 pc. Small tubing clamp
E. 1 pc. Large tubing clamp
F. Metering Tip Kit
G. 1 pc. ea. Tubing with foot valve, ceramic weight
II.

CHEMICAL ADJUSTMENT:

CAUTION: Be careful when working with hazardous chemicals.
Select metering tip using Table 1 as a guide. Screw tip into inlet barb of injector.
III. INSTALLATION:
CAUTION: All work done should adhere to all applicable plumbing codes.
1. Slip ceramic weight over small diameter tubing. Attach tubing to inlet barb under bung cap and secure with small clamp.
2. Insert tubing into chemical and screw bung cap into drum opening.
3. Slip outlet tubing (large diameter) over threads of injector. Secure with large tubing clamp and cut to convenient length.
4. Attach water supply hose (not provided) to water inlet and tighten.
Tip Color
Turquoise
Black
Gray
Red
Blue
Brown
White
Orange
Clear
No Tip

RETURNS:

NO MERCHANDISE MAY BE RETURNED FOR CREDIT WITHOUT DEMA'S WRITTEN
PERMISSION.
ADVANCE OF RETURN.

WARRANTY:

DEMA products are warranted against defective material and workmanship under normal use and service
for one year from the date of manufacture. This limited warranty does not apply to any products which
have a normal life shorter than one year or failure and damage caused by chemicals, corrosion, improper
voltage supply, physical abuse, or misapplication. Rubber and synthetic rubber parts such as "o"- rings,
diaphragms, squeeze tubing and gaskets are considered expendable and are not covered under warranty.
This warranty is extended only to the original buyer of DEMA products. If products are altered or
repaired without prior approval of DEMA, this warranty will be void.
Defective units or parts should be returned to the factory with transportation prepaid. If inspection shows
them to be defective, they will be repaired or replaced without charge, F.O.B. factory. DEMA assumes no
liability for damages.
replacement, must be granted in advance of return.
I-644
Rev. B 02/01
DEMA MODEL 607DM-BM
DRUM MOUNT HIGH-FLOW FILL STATION

INSTALLATION INSTRUCTIONS

Induction readings taken at 11 GPM and 40 psi.
1 cps
Oz./Gal. Ratio
1.46 87.91
1.86 68.78
2.20 58.31
2.94 43.50
3.39 37.76
4.36 29.39
5.63 22.74
7.03 18.20
12.76 10.03
21.88 5.85
RETURN MERCHANDISE AUTHORIZATION NUMBER REQUIRED IN
Return merchandise authorization number, to return units for repair or

Table 1

75 cps
Oz./Gal. Ratio
1.13 113.00
1.28 99.82
1.73 73.83
2.38 53.67
2.82 45.37
3.77 33.94
4.73 27.08
5.45 23.47
- -
9.93 12.89
200 cps
Oz./Gal. Ratio
1.07 119.57
1.31 97.62
1.70 75.38
1.97 64.98
2.21 57.94
2.83 45.25
3.16 40.56
3.44 37.19
- -
4.46 28.67
Pg. 1 of 2
