DEMA 607T-MC Installation Instruction

DEMA MODEL 607T-MC HI-FLOW FILL STATION
1.

PARTS:

A. Fill Station Assembly (1 each)
B. Mounting Screws and Anchors (4 each)
C. 10' Long Outlet Tubing with Priming Ring (1 each)
D. Tubing Clamp (1 each)
2.

INSTALLATION:

CAUTION: ALL WORK DONE SHOULD ADHERE TO ALL APPLICABLE
PLUMBING CODES.
1. Remove Fill Station cover and hold assembly to wall, locate positions of mounting screws. Drill
holes in wall about 1" deep. Mount assembly to wall using screws and anchors provided. After
mounting the assembly onto the wall, reinstall cover onto the assembly.
2. Slip outlet tubing (large diameter) over threads of injector. Secure with tubing clamp and cut to
convenient length.
3. Attach water supply hose (not provided) to water inlet and tighten.

RETURNS:

WARRANTY:

I-619
REV. --
INSTALLATION INSTRUCTION
NO MERCHANDISE MAY BE RETURNED FOR CREDIT WITHOUT DEMA'S
WRITTEN PERMISSION.
NUMBER REQUIRED IN ADVANCE OF RETURN.
DEMA products are warranted against defective material and workmanship under
normal use and service for one year from the date of manufacture. This limited
warranty does not apply to any products which have a normal life shorter than one year
or failure and damage caused by chemicals, corrosion, improper voltage supply, physical
abuse, or misapplication.
diaphragms, squeeze tubing and gaskets are considered expendable and are not covered
under warranty. This warranty is extended only to the original buyer of DEMA
products. If products are altered or repaired without prior approval of DEMA, this
warranty will be void.
Defective units or parts should be returned to the factory with transportation prepaid. If
inspection shows them to be defective, they will be repaired or replaced without charge,
F.O.B. factory. DEMA assumes no liability for damages.
authorization number, to return units for repair or replacement, must be granted in
advance of return.
RETURN MERCHANDISE AUTHORIZATION
Rubber and synthetic rubber parts such as "o"- rings,
Return merchandise
Page 1 of 3
