ResMed Swift FX for Her Fittings Manual

Swift FX
™
for Her
NASAL PILLOWS SYSTEM
Fitting Guide
1
• Holding the pillows at your nose, • Adjust the top strap first.
pull the headgear over your head.
• Pull the strap through the buckle
• Headgear should sit midway one notch at a time.
between the ears and eyes.
• Do not overtighten.
4
• Swift ™ FX for Her pillows are • Connect the Swift FX for Her short
designed to provide a natural fit. tube to the device air tubing.
• Minor adjustment can help • Swift FX for Her is now fitted and
position the pillows at the most ready for use.
comfortable angle in the nose.
OPtiOnAl SOFT WRAPS
• Wrap each of the soft wraps • The soft wraps should be
around either side of the
headgear, folding the top
fastener over the lower one.
ResMed Corp San Diego, CA, USA +1 858 836 5000 or 1 800 424 0737 (toll free). ResMed Ltd Bella Vista, NSW, Australia +61 (2) 8884 1000 or 1 800 658 189 (toll free). See www.resmed.com for other ResMed locations
worldwide. Swift is a trademark of ResMed Ltd and is registered in the U.S. Patent and Trademark Office. Breathe-O-Prene is a trademark of AccuMED Technologies, Inc. Velcro is a trademark of Velcro Industries B.V.
©2010 ResMed. Specifications may change without notice. 1014015/2 10 08
Global leaders in sleep and respiratory medicine
2
• Adjust the backstrap to fine-tune
the fitting if necessary.
• Do not overtighten.
• The backstrap can be positioned
over or under the hair.
5
TIP
• With the device turned on, check
that the nasal pillows are properly
inflated. To do this, pull the nasal
Pillows away from the face and
cheek, make sure they are inflated
and reposition them in the nose.
positioned on the cheeks,
with the fasteners on the
outside.
www.resmed.com
Swift
™
NASAL PILLOWS SYSTEM
Less mask. More you.
The Swift FX for Her combines soft,
™
lightweight design with a fit range
specialized for women to meet women's
unique needs.
• A choice of pink or light blue and gray
backstrap lets you personalize your mask
to fit your style
3
• Minimal design reinforces sense of
freedom
• Unprecedented softness, simplicity
and stability
• Flexible, fluid form conforms to facial
contours and user movements
• Promotes early therapy acceptance
• Intuitive, virtually instant fitting
• Stable performance, even at
high pressures
dual-wall nasal pillows
seal on contact for a gentle,
comfortable seal, offer a wide
fit range and disperse air
gently to the nose
Soft, narrow cushion with
integrated flexible chamber
makes side sleeping
comfortable and helps
maintain seal during
movement
Ultra-smooth 360°
rotating elbow
rotates with easy, fluid
movement for flexibility in
tube positions
Quiet vents
diffuse and direct airflow
quietly away from the user
and bed partner
Spring-flex lightweight
tube stretches and bends
uniquely for increased
stability without the use
of a tube retainer
FX
for Her
Simple top buckle
has clearly marked notches
for easy adjustment.
Additional buckle notches
allow customized sizing for
women's unique fitting needs
Soft silicone headgear
embraces the face
gently and needs minimal
adjustment
low-profile backstrap
with Velcro ® fasteners
are available in small
sizes, in a feminine pink
or light blue and gray
Soft Wraps
enhance comfort at the cheeks. Soft
wraps available in gray and pink to
color coordinate with backstrap
Size and name indicators
make it easy to identify the size as
well as the correct orientation of
the mask
"lock and key"
for easy attachment and
detachment of side straps
Flexible pillows with trampoline action
accommodate movement in multiple
directions while maintaining seal. Pillow
sizes for her (XS, S and M) come packaged
with mask to fit most female patients
