- Page 1 Swift FX Nano ™ Swift FX Nano for Her ™ nasal Mask User Guide English...
- Page 2 Swift FX Nano ™ Swift FX Nano for Her ™ nasal mask / 鼻面罩 / 鼻面罩 Fitting / 配戴步骤 / 配戴步驟...
- Page 3 Removal / 取下面罩 / 取下面罩 Disassembly / 拆卸 / 拆卸...
- Page 4 Reassembly / 重新组装 / 重新組裝...
- Page 6 Mask components / 面罩组件 / 面罩組件 Part number / 配件编号 / 配件編號 Item / Description / 描述 / 描述 产品 / Swift FX Swift FX 產品 Nano Nano for Her (女用 / 女用) Headgear right / 右头带 / 右頭帶 Top buckle / 上端搭扣 / 上端搭扣 Back strap / 后束带 / 後束帶 Back strap fastener / 后束带扣钩 / 後束帶扣鉤...
- Page 7 S: Small /小型 / 小型 Std: Standard / 标准 / 標準 W: Wide / 宽 / 寬型 G: Gray / 灰色 / 灰色 P: Pink / 粉色 / 粉色...
-
Page 8: General Warnings
Swift FX Nano for Her ASAL Thank you for choosing the Swift FX Nano / Swift FX Nano for Her. Please read the entire manual before use. Intended Use The Swift FX Nano / Swift FX Nano for Her channels airflow noninvasively to a patient from a continuous positive airway pressure (CPAP) or bilevel device. - Page 9 circumstances, lead to suffocation. This applies to most models of CPAP or bilevel devices. Follow all precautions when using supplemental oxygen. Oxygen flow must be turned off when the CPAP or bilevel device is not operating, so that unused oxygen does not accumulate within the device enclosure and create a risk of fire.
-
Page 10: Using Your Mask
Using your mask When using your mask with ResMed CPAP or bilevel devices that have mask setting options, refer to the Technical specifications section in this user guide for mask selection options. For a full list of compatible devices for this mask, see the Mask/Device Compatibility List on www.resmed.com on the... -
Page 11: Removing Your Mask
Removing your mask To remove your mask pull the mask and headgear by the fabric back strap up and over your head. Disassembly Refer to the disassembly illustrations in this user guide. A diagram showing the names of parts can be found in the Mask Components diagram near the beginning of this guide. -
Page 12: Cleaning Your Mask In Your Home
7. Thread the fabric back strap through each side of the headgear, then fold over to secure. Ensure that the fastener is on the outside with the ResMed logo facing out. Cleaning your mask in your home Your mask and headgear should only be handwashed by gently rubbing in warm (approximately 30°C) water using mild soap. -
Page 13: Reprocessing The Mask Between Patients
Reprocessing the mask between patients This mask should be reprocessed when used between patients. Cleaning, disinfection and sterilization instructions are available from the ResMed website, www.resmed.com/masks/sterilization. If you do not have internet access, please contact your ResMed representative. Troubleshooting Problem/possible cause Solution Mask is too noisy. - Page 14 Problem/possible cause Solution Mask leaks around face. Mask is not positioned correctly. Check that the ResMed logo is facing upward on the top of the cushion across the bridge of your nose. Mask may have been fitted Pull the mask away from your face incorrectly.
-
Page 15: Technical Specifications
Problem/possible cause Solution Mask does not fit properly. Mask is incorrectly assembled. Disassemble the mask, then reassemble according to the instructions. Ensure that the swivel ring on the elbow has not been inserted too far into the cushion. Check that the printing on the left headgear strap (Swift FX) aligns to the printing on the cushion arm (Nano). - Page 16 Environmental Operating temperature: conditions +5°C to +40°C Operating humidity: 15% to 95% relative humidity non-condensing Storage and transport temperature: -20°C to +60°C Storage and transport humidity: 15% to 95% relative humidity non-condensing Sound DECLARED DUAL-NUMBER NOISE EMISSION VALUES in accordance with ISO 4871. The A-weighted sound power level of the mask is 25 dBA, with uncertainty of 3 dBA.
-
Page 17: Limited Warranty
This warranty is only available to the initial consumer. It is not transferable. If the product fails under conditions of normal use, ResMed will repair or replace, at its option, the defective product or any of its components. This limited warranty does not cover: a) any damage caused as a result of improper use, abuse, modification or alteration of the product;... - Page 18 ResMed shall not be responsible for any incidental or consequential damages claimed to have resulted from the sale, installation or use of any ResMed product. Some regions or states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation may not apply to you.
- Page 19 See www.resmed.com for other ResMed locations worldwide. For patent information, see www.resmed.com/ip Swift is a trademark of ResMed Ltd and is registered in U.S. Patent and Trademark Office. Velcro is a trademark of Velcro Industries B.V. © 2013 ResMed Ltd.
- Page 20 Swift FX Nano for Her NASAL MASK...
- Page 21 628037/2 2013-01 Swift FX Nano / Swift FX Nano for Her USER Swift FX Nano APAC eng NASAL MASK 628037 Global leaders in sleep and respiratory medicine www.resmed.com...
