- Page 1 OPERATIONS MANUAL ba76136e04 10/2017 4120(W) / 4130(W) PH COMBINATION ELECTRODES WITH REFILLABLE LIQUID REFERENCE SYSTEM...
- Page 2 4120(W) / 4130(W) Contact 1725 Brannum Lane Yellow Springs, OH 45387 USA Tel: +1 937-767-7241 800-765-4974 Email: environmental@ysi.com Internet: www.ysi.com © 2017 Xylem Inc. Copyright ba76136e04 10/2017...
-
Page 3: General Information
4120(W) / 4130(W) General information General information Automatic sensor The sensor electronics with the stored sensor data are in the connecting recognition head of the electrode. The data include, among other things, the sensor type and series number. In addition, the calibration data are stored in the sensor with each calibration and the calibration history is recorded (the last 10 cali- brations). - Page 4 Commissioning, measuring, calibration 4120(W) / 4130(W) Please keep the watering cap. It is required for the electrode to be stored. Always keep the watering cap clean. 4120(W): Remove any gas bubbles behind the pH membrane by shaking. Connect the electrode to the meter. 4120 /4130 –...
- Page 5 4120(W) / 4130(W) Commissioning, measuring, calibration Plug connection closed and locked Guidance Groove Opening the plug If necessary, clean the plug connection. connection Open the locking device (step 1). Use your thumb and index finger to press the clips of the connector together, and pull the connector out of the plug (step 2).
- Page 6 Storage 4120(W) / 4130(W) measurement to the next by taking the following measures: – Shortly rinse the calibration and sample beakers with the solution the beakers are to be filled with next. – Between measurements, rinse the electrode with the solution that fol- lows.
-
Page 7: Maintenance And Cleaning
4120(W) / 4130(W) Aging NOTE pH electrodes must not be stored dry or in deionized water. The elec- trode could be permanently damaged by this. If the liquid in the watering cap has dried up, condition the electrode in reference electro- lyte (KCl 3 mol/l, Ag+ free) for at least 24 hours. -
Page 8: Technical Data
Technical data 4120(W) / 4130(W) Cleaning Remove water-soluble contamination by rinsing with deionized water. Remove other contamination as follows: Contamination Cleaning procedure Fat and oil Rinse with water containing household wash- ing-up liquid Lime and hydroxide deposits Rinse with citric acid (10 % by weight) NOTE Hydrofluoric acid, hot phosphoric acid and strong alkaline solutions destroy the glass membrane. - Page 9 4120(W) / 4130(W) Technical data General features Reference electrolyte KCl 3 mol/l, Ag free Junction Ceramic (4120(W)) Platinum (4130(W)) Temperature sensor Integrated NTC 30 (30 kat 25 °C / 77 °F) Connection cable Lengths 4120(W) / 4130(W): 1,5 4120(W) / 4130(W)W:1,5 / 3 m Diameter 4.3 mm Smallest allowed...
-
Page 10: Wear Parts And Accessories
Wear parts and accessories 4120(W) / 4130(W) Wear parts and accessories Maintenance Description Model Order no. equipment Reference electrolyte solution 250 ml KCl-250 109 705Y to fill the watering cap (KCl 3 mol/l, Ag -free) Connection cable Description Model Order no. 4120(W) / 4130(W) - IDS connection cable, 1.5 m IDS-CABLE-... -
Page 11: Contact Information
When returning a product for service, include the Product Return form with cleaning certification. The form must be completely filled out for an YSI Service Center to accept the instrument for service. The Product Return form may be downloaded at www.ysi.com... - Page 12 Contact Information 4120(W) / 4130(W) ba76136e04 10/2017...
- Page 14 For more information on how Xylem can help you, go to www.xyleminc.com 1725 Brannum Lane Yellow Springs, OH 45387 Tel: +1 937-767-7241; 800-765-4974 Fax: +1 937-767-1058 Email: environmental@ysi.com Web: www.ysi.com ©Xylem Inc...
