Summary of Contents for YSI 4110W
- Page 1 BEDIENUNGSANLEITUNG OPERATING MANUAL ba76137d04 10/2017 4110(W) / 4110-3 pH ELECTRODES WITH GEL ELECTROLYTE...
- Page 2 4110 Contact 1725 Brannum Lane Yellow Springs, OH 45387 USA Tel: +1 937-767-7241 800-765-4974 Email: environmental@ysi.com Internet: www.ysi.com © Copyright 2017 Xylem Inc. ba76137d04 10/2017...
-
Page 3: General Information
4110(W) General information General information Automatic sensor The sensor electronics with the stored sensor data are in the connecting recognition head of the electrode. The data include, among other things, the sensor type and series number. In addition, the calibration data are stored in the sensor with each calibration and the calibration history is recorded (the last 10 cali- brations). - Page 4 IDS connector on the meter – wireless via an IDS WA-S adapter (acces- sory) to a WA-capable meter Accessories for the connection of the 4110W sensor to the meter: See chapter 7 W PARTS AND ACCESSORIES Opening and closing the IDS plug connection, see section 2.2 O...
- Page 5 4110(W) General information Opening and closing the IDS plug connection This section only applies to IDS plug variants (4110W). Plug connection closed and locked Guidance Groove If necessary, clean the plug connection. Opening the plug connection Open the locking device (step 1).
- Page 6 Storage 4110(W) Calibration and measurement: General rules Avoid the carryover of any solution (sample or buffer solution) from one measurement to the next by taking the following measures: – Shortly rinse the calibration and sample beakers with the solution the beakers are to be filled with next.
-
Page 7: Maintenance And Cleaning
4110(W) Aging Overnight or Put the clean electrode in the watering cap that is filled with reference elec- longer trolyte (KCl 3 mol/l, Ag free). NOTE pH electrodes must not be stored dry or in deionized water. The elec- trode could be permanently damaged by this. If the liquid in the watering cap has dried up, condition the electrode in reference electro- lyte (KCl 3 mol/l, Ag+ free) for at least 24 hours. -
Page 8: Technical Data
(4110(W)) Temperature sensor Integrated NTC 30 (30 kat 25 °C / 77 °F) Connection cable Lengths 4110: 1,5 / 3 m 4110W: 1,5 / 3 m Diameter 4.3 mm Smallest allowed Fixed installation:20 mm bend radius Flexible use:60 mm Plug type... -
Page 9: Wear Parts And Accessories
4110(W) Wear parts and accessories Model Reference Junction Special fatures Double junction elektrolyte 4110 Fiber Plastic shaft 4110-3 Fiber Plastic shaft Wear parts and accessories Maintenance Description Model Order no. equipment Reference electrolyte solution 250 ml KCl-250 109 705Y to fill the watering cap (KCl 3 mol/l, Ag -free) Connection cable... - Page 10 Disposal 4110(W) ba76137d04 10/2017...
-
Page 11: Contact Information
When returning a product for service, include the Product Return form with cleaning certification. The form must be completely filled out for an YSI Service Center to accept the instrument for service. The Product Return form may be downloaded at www.ysi.com... - Page 12 Contact Information 4110 ba76137d04 10/2017...
- Page 14 For more information on how Xylem can help you, go to www.xyleminc.com 1725 Brannum Lane Yellow Springs, OH 45387 Tel: +1 937-767-7241; 800-765-4974 Fax: +1 937-767-1058 Email: environmental@ysi.com Web: www.ysi.com ©Xylem Inc...
