Overview
Pos.
1 FHG Turbo 3000 Firewood Boiler
2 Insulating door for reduced heat radiation
3 Fuel loading door
4 Pre-heating chamber door
5 Combustion chamber door
Side cleaning port door
6
7 Lambdatronic S3100 Control System
7.1 HEATING 1-4 (Auto/Off/Manual)
7.2 PUMP 1-3 (Auto/Off/Manual)
7.3 HTG 0 / OIL (Auto/Off/Manual)
7.4 BLOWER FAN (Auto/Off/Manual)
7.5 The respective LED illuminates when Pos. 7.1 – 7.4 are active
7.6 Status LED (Operating Status): - long, green blinking light: Boiler activated
7.7 START key: Switch on boiler
7.8 STOP key: Switch off boiler (not possible during heating operation)
7.9 MENU keys: Manipulate the program menus
7.10 Two-line display for indicating the operating statuses
8 Digitronic S3100 Control System
8.1 INDUCED DRAUGHT UNIT (Automatic/Off/Manual)
CIRCUIT 1-2 (Automatic/Off/Manual)
8.2
8.3 Controller for adjusting: flue gas temperatures, air status, boiler temperature
8.4 3-digit display for indicating: boiler temperature, flue gas temperature, Pos. 8.3 controller
settings
8.5 Heating circuit pump (HKP) status LED: illuminates on reaching the release temperature for the
heating circuit pump
8.6 START key: Switch on boiler
STOP key: Switch off boiler (not possible during heating operation)
8.7
9 Main switch: switches the system on and off
10 STB – Safety Temperature Limiter
11 Power network fusing of the controller (glass-tube fusing 20 x 5mm 10AT)
