SCOUT II
Power
Mini-USB/Charging/Analog
Task Light
video out of Mini-USB port
Power Button – The Scout II has three power states: On, Off, and Auto Shutdown.
• On – Takes approximately 4 seconds (during bootup the FLIR splash screen
appears on the eyepiece display).
• Off – Push the power button to turn the camera off.
• Auto Shutdown - If no buttons are pushed for about five minutes,
Auto shutdown 30s appears in the display and after counting down for
30 seconds, the camera will turn off.
Display Brightness – If camera is on, press to toggle through 5 brightness settings.
White/Black Hot/InstAlert
grey. In the Black Hot, hotter items appear as black or dark grey. In InstAlert
in a scene are highlighted in red.
Zoom/Freeze Frame – A quick press causes the image to toggle between 1x and 2x
zoom (320 model only). With the 240 camera, the zoom button freezes the image with
one click and unfreezes the image with a second click.
Diopter Controls – The diopter allows adjustment of the eyepiece for optimal viewing.
Q u ick Sta rt Gui de
Display Brightness
Task Light On/Off
– In White Hot, hotter items appear as white or light
™
Zoom 320 / Freeze Frame 240
Charging
Indicator
White Hot
Black Hot
InstAlert
™
Eyepiece
Adjustable Diopter
, hot items
™
