  • Page 1 Original instructions Diesel truck RX70-16 RX70-18 RX70-20 7311 7312 7313 174749 EN - 03/2017...
  • Page 3 Preface Address of manufacturer and contact details STILL GmbH Berzeliusstraße 10 22113 Hamburg, Germany Tel. +49 (0) 40 7339-0 Fax: +49 (0) 40 7339-1622 Email: info@still.de Website: http://www.still.de 174749 EN - 03/2017...

  • Page 5: Table Of Contents

    Table of contents Foreword Your truck ............2 Description of the truck .
  • Page 6 Table of contents Damage, defects and misuse of safety systems ......30 Tyres .
  • Page 7 Table of contents Operation Testing and activities before daily use ........68 Visual inspections .
  • Page 8 Table of contents Actuating the vertical rocker switch for the "drive direction", joystick 4Plus version ..124 Actuating the drive direction switch, fingertip version ......124 Actuating the drive direction switch, mini-console version .
  • Page 9 STILL SafetyLight (variant) ........
  • Page 10 Table of contents Heating system ........... . . 228 Push-up roof window (variant) .
  • Page 11 Table of contents Maintenance Safety instructions for maintenance ........300 General information .
  • Page 12 Dimensions ............348 VDI datasheet for RX70-16, RX70-18 and RX70-20 .

  • Page 13: Foreword

    Foreword...

  • Page 14: Your Truck

    Your truck Description of the truck General The internal combustion engine-powered trucks of series RX70-16/18/20 with a load capacity of up to 2 t are equipped with a diesel-electric drive. The diesel-electric drive combines the advantages of the diesel engine with the precise control of an electric drive.
  • Page 15 Foreword Your truck cooled by means of a closed coolant circuit. The engine is lubricated via forced circulation lubrication. The combustion air is drawn in and cleaned by a dry air filter. Different equipment variants are available, for example a diesel particle filter.

  • Page 16: General

    Foreword Your truck Operating devices The truck is characterised by an accessible operating concept. When purchasing the truck, a variety of controls and equipment variants are available: • Double mini-lever • Triple mini-lever • Quadruple mini-lever • Joystick 4Plus • Fingertip switch •...

  • Page 17: Ce Labelling

    Foreword Your truck CE labelling The manufacturer uses CE labelling to indi- cate that the truck complies with the standards and regulations valid at the time of marketing. This is confirmed by the issued EC declaration of conformity. The CE labelling is attached to the nameplate.

  • Page 18: Ec Declaration Of Conformity In Accordance With Machinery Directive

    Foreword Your truck EC declaration of conformity in accordance with Machinery Directive Declaration STILL GmbH Berzeliusstraße 10 D-22113 Hamburg Germany We declare that the according to these operating instructions Industrial truck according to these operating instructions Model conforms to the latest version of the Machinery Directive 2006/42/EC.

  • Page 19: Accessories Overview

    Foreword Your truck Accessories overview • Key for key switch (2 pieces) • Key for cab (variant) • Hexagon socket wrench for emergency lowering 174749 EN - 03/2017...

  • Page 20: Overview

    Foreword Your truck Overview DANGER DANGER DANGER DANGER 10 bar DANGER STILL GmbH Hamburg Regelmäßige Prüfung (FEM 4.004) nach nationalen Vorschriften basierend auf den EG-Richtlinien: 2009/104/EG, 99/92/EG Nächste Prüfung DANGER 20xx Die Prüfplakette ersetzt nicht das Prüfprotokoll Mitglied der: Fédération Européene...
  • Page 21 Foreword Your truck Decal information: "Dual-pedal operation" Decal information: Parking brake applied (variant) Warning sign: Danger due to shearing / Manufacturer's label text Danger due to high fluid pressure Decal information: FEM audit Warning sign: Do not stand underneath the Inspection sticker fork / Do not stand on the fork Warning sign: Passengers are not allowed...

  • Page 22: Nameplate

    Foreword Your truck Nameplate The truck can be identified from the informa- tion on the nameplate. Type-Modèle-Typ / Serial no.-No. de série-Serien-Nr. / year-année-Baujahr Rated capacity Unladen mass Capacité nominale Masse à vide Nenn-Tragfähigkeit Leergewicht Battery voltage Tension batterie Batteriespannung min.* Rated drive power Puissance motr.nom.

  • Page 23: Production Number

    Foreword Use of truck Production number xx xxxx x xxxxx NOTE The production number is used to identify the truck. It can be found on the nameplate and must be referred to in all technical questions. The production number contains the following coded information: (1) Production location (2) Model...

  • Page 24: Proper Use During Towing

    Foreword Use of truck The truck may only be used for its proper purpose as set out and described in these operating instructions. If the truck is to be used for purposes other than those specified in the operating instruc- tions, the approval of the manufacturer and, if applicable, the relevant regulatory authorities must be obtained beforehand to prevent haz-...

  • Page 25: Place Of Use

    Foreword Use of truck The truck may not be operated in areas where there is a risk of fire, explosion or corrosion, or in areas that are particularly dusty. Stacking or unstacking is not permissible on inclined surfaces or ramps. Place of use The truck can be used outdoors.

  • Page 26: Using Working Platforms

    Foreword Use of truck NOTE Please observe the definition of the following responsible person: "operating company". DANGER Risk to health from exhaust gases! Exhaust gases from internal combustion engines are harmful to your health. In particular, the soot particles contained in the diesel exhaust gas can cause cancer.

  • Page 27: Information About Documentation

    Foreword Information about documentation Information about documentation Documentation scope • Original operating instructions • Original operating instructions for attach- ments (variant) • Spare parts list • VDMA rules for the proper use of industrial trucks • Depending on the truck equipment, "UPA" operating instructions may also be provided These operating instructions describe all measures necessary for the safe operation...

  • Page 28: Supplementary Documentation

    Foreword Information about documentation The operating company must ensure that all users have received, read and understood these operating instructions. NOTE Please observe the definition of the following responsible persons: "operating company" and "driver". Thank you for reading and complying with these operating instructions.

  • Page 29: Issue Date And Topicality Of The Operating Instructions

    The issue date of these operating instructions can be found on the title page. STILL is constantly engaged in the further development of trucks. These operating instructions are subject to change, and any claims based on the information and/or illustrations contained in them cannot be asserted.

  • Page 30: List Of Abbreviations

    Foreword Information about documentation ENVIRONMENT NOTE To prevent environmental damage. List of abbreviations NOTE This list of abbreviations applies to all types of operating instructions. Not all of the abbre- viations that are listed here will necessarily appear in these operating instructions. Abbrevi- Meaning Explanation...
  • Page 31 Foreword Information about documentation Abbrevi- Meaning Explanation ation Transfer of data packets in wireless GPRS General Packet Radio Service networks ID no. ID number International Organization for Standard- International standardisation organisation ization Local Area Network Local area network Uncertainty of measurement of sound pressure levels Light Emitting Diode Light emitting diode...

  • Page 32: Definition Of Directions

    Foreword Information about documentation Definition of directions The directions "forwards" (1), "backwards" (3), "right" (2) and "left" (4) refer to the installation position of the parts as seen from the driver's compartment; the load is to the front. 6210_001-031 Schematic views View of functions and operations This documentation explains the (usually sequential) chain of certain functions or oper-...
  • Page 33 Foreword Information about documentation View of the display operating unit NOTE Views of operating statuses and values in the display of the display operating unit are examples and partly dependent on the truck equipment. As a result, the displays shown of the actual operating statuses and values can vary.

  • Page 34: Environmental Considerations

    Foreword Environmental considerations Environmental considerations Packaging During delivery of the truck, certain parts are packaged to provide protection during transport. This packaging must be removed completely prior to initial start-up. ENVIRONMENT NOTE The packaging material must be disposed of properly after delivery of the truck. Disposal of components and batteries The truck is composed of different materials.

  • Page 35: Safety

    Safety...

  • Page 36: Definition Of Responsible Persons

    Safety Definition of responsible persons Definition of responsible persons Operating company The operating company is the natural or legal person or group who operates the truck or on whose authority the truck is used. The operating company must ensure that the truck is only used for its proper purpose and in compliance with the safety regulations set out in these operating instructions.

  • Page 37: Drivers

    Safety Definition of responsible persons regarding the industrial truck to be tested and the risk being assessed Drivers This truck may only be driven by suitable per- sons who are at least 18 years of age, have been trained in driving, have demonstrated their skills in driving and handling loads to the operating company or an authorised rep- resentative, and have been specifically in-...
  • Page 38 Safety Definition of responsible persons DANGER The use of drugs, alcohol or medications that affect reactions impair the ability to drive the truck! Individuals under the influence of the aforementio- ned substances are not permitted to perform work of any kind on or with the truck. Prohibition of use by unauthorised persons The driver is responsible for the truck during...

  • Page 39: Essentials For Safe Operation

    Safety Essentials for safe operation Essentials for safe operation Insurance cover on company premises In many cases, company premises are restricted public traffic areas. NOTE The business liability insurance should be reviewed to ensure that, in the event of any damage caused in restricted public traffic areas, there is insurance cover for the truck in respect of third parties.
  • Page 40 Safety Essentials for safe operation DANGER Risk of injury! Even when using an approved restraint system, there is some residual risk that the driver might be injured if the truck tips over. This risk of injury can be reduced through the combined use of the restraint system and the seat belt.

  • Page 41: Changes To The Overhead Guard And Roof Loads

    Original parts, attachments and accessories are specially designed for this truck. We specifically draw your attention to the fact that parts, attachments and accessories supplied by other companies have not been tested and approved by STILL. 174749 EN - 03/2017...

  • Page 42: Damage, Defects And Misuse Of Safety Systems

    Safety Essentials for safe operation CAUTION Installation and/or use of such products may there- fore have a negative impact on the design features of the truck and thus impair active and/or passive driving safety. We recommend that you obtain approval from the manufacturer and, if necessary, from the relevant regulatory authorities before installing such parts.
  • Page 43 Safety Essentials for safe operation The following factors can lead to a loss of stability and are therefore prohibited: • Different tyres on the same axle, e.g. pneumatic tyres and superelastic tyres • Tyres not approved by the manufacturer • Excessive tyre wear •...

  • Page 44: Medical Equipment

    Safety Essentials for safe operation Medical equipment WARNING Electromagnetic interference may occur on medical devices! Only use equipment that is sufficiently protected against electromagnetic interference. Medical equipment, such as pacemakers or hearing aids, may not work properly when the truck is in operation. –...

  • Page 45: Length Of The Fork Arms

    Safety Essentials for safe operation Length of the fork arms DANGER Risk of accident due to the incorrect selection of fork arms! – The fork arms must match the depth of the load. If the fork arms are too short, the load may fall off the arms after it has been picked up.

  • Page 46: Residual Risk

    Safety Residual risk Residual risk Residual dangers, residual risks Despite careful working and compliance with standards and regulations, the occurrence of other risks when using the truck cannot be entirely excluded. The truck and all other system components comply with current safety requirements. Nevertheless, even when the truck is used for its proper purpose and all instructions are followed, some residual risk cannot be...

  • Page 47: Special Risks Associated With Using The Truck And Attachments

    Safety Residual risk The manufacturer is not held responsible for accidents involving the truck caused by the failure of the operating company to comply with these regulations either intentionally or carelessly. Stability The stability of the truck has been tested to the latest technological standards and is guaran- teed provided that the truck is used properly and according to its intended purpose.
  • Page 48 Safety Residual risk time the truck is used in a manner that falls outside the scope of normal use, and in cases where the driver is not certain that he can use the truck correctly and without the risk of acci- dents.
  • Page 49 Safety Residual risk 174749 EN - 03/2017...

  • Page 50: Overview Of Hazards And Countermeasures

    Safety Residual risk Overview of hazards and counter- measures NOTE This table is intended to help evaluate the hazards in your facility and applies to all drive types. It does not claim to be complete. – Observe the national regulations for the country in which the truck is being used.
  • Page 51 Safety Residual risk Hazard Measure Check note Notes √ Complete - Not applicable Impermissible usage Issuing of operating German Ordinance on (improper usage) instructions Industrial Safety and Health (BetrSichV) and German Health and labour protection law (ArbSchG) Written notice of German Ordinance on instruction to driver Industrial Safety and...
  • Page 52 Safety Residual risk Hazard Measure Check note Notes √ Complete - Not applicable When charging the Note the German Association for traction battery Ordinance on Electrical, Electronic Industrial Safety and and Information Health (BetrSichV), Technologies (VDE) the operating regulation 0510: In instructions and the particular German Engineering...

  • Page 53: Danger To Employees

    Safety Residual risk Danger to employees According to the German Ordinance on Indus- trial Safety and Health (BetrSichV) and labour protection law (ArbSchG), the operating com- pany must determine and assess hazards during operation, and establish the labour protection measures required for employ- ees (BetrSichVO).

  • Page 54: Safety Inspections

    – Check the diesel engine emissions annually to TRGS 554. The exhaust-gas check is to be carried out by a specialist (see ⇒ Chapter "Definition of responsible persons", P. 24) and must be recorded in writing. – Contact your STILL service centre. 174749 EN - 03/2017...

  • Page 55: Trucks With Particle Filters

    Safety Safety inspections NOTE Observe the national regulations for your country! Trucks with particle filters Trucks with particle filters (variant) may be operated in completely or partially enclosed working areas. DANGER Risk to health from exhaust gases! Exhaust gases from internal combustion engines are harmful to your health.

  • Page 56: Insulation Testing

    Safety Safety inspections NOTE Please observe the definition of the following responsible persons: "operating company" and "competent person". NOTE Observe the TRGS 554 regulations and national regulations of the country in which the truck is being used. Insulation testing The truck insulation must have sufficient insu- lation resistance.

  • Page 57: Safety Regulations When Handling Consumables

    Safety Safety regulations when handling consumables Safety regulations when handling consumables Permissible consumables DANGER Failure to observe the safety regulations relating to consumables may result in a risk of injury, death or damage to the environment. – Observe the safety regulations when handling such materials.

  • Page 58: Hydraulic Fluid

    Safety Safety regulations when handling consumables WARNING Prolonged intensive contact with the skin can result in dryness and irritate the skin! – Avoid contact and consumption. – Wear protective gloves. – After any contact, wash the skin with soap and water, and then apply a skin care product.

  • Page 59: Battery Acid

    Safety Safety regulations when handling consumables WARNING These fluids are pressurised during operation of the truck and are hazar- dous to your health. – Do not allow the fluids to come into contact with the skin. – Avoid inhaling spray. –...

  • Page 60: Diesel Fuel

    Safety Safety regulations when handling consumables WARNING Battery acid contains dissolved sulphuric acid. This is corrosive. – When working with battery acid, use appropriate PSA (rubber gloves, apron, protection goggles). – When working with battery acid, never wear a watch or jewellery. –...
  • Page 61 Safety Safety regulations when handling consumables WARNING Prolonged intensive contact with the skin can result in loss of skin oils and can irritate the skin! – Avoid contact and swallowing. – Wear protective gloves. – After any contact, wash the skin with soap and water, and then apply a skin care product.

  • Page 62: Coolant And Cooling Fluid

    Safety Safety regulations when handling consumables Coolant and cooling fluid WARNING Coolant and cooling fluid can be hazardous to your health and the environment! Coolants are chemical corrosion inhi- bitors and cooling system protecting agents such as Glysantin. Cooling fluid is an appropriate mixture of water and coolant.
  • Page 63 Safety Safety regulations when handling consumables – Neutralise any spilt battery acid immedi- ately. – Always observe national regulations con- cerning the disposal of used oil. 174749 EN - 03/2017...

  • Page 64: Emissions

    Safety Emissions Emissions The values specified apply to a standard truck (compare the specifications in the "Technical data" chapter). Different tyres, lift masts, additional units etc. may produce different values. Noise emissions The values were determined based on measuring procedures from the standard EN 12053 "Safety of industrial trucks.
  • Page 65 Safety Emissions Vibrations The vibrations of the machine have been determined on an identical machine in ac- cordance with the standards DIN EN 13059 "Safety of industrial trucks - Test methods for measuring vibration" and DIN EN 12096 "Mechanical vibration - Declaration and verifi- cation of vibration emission values".
  • Page 66 Safety Emissions Exhaust gases DANGER Risk to health from exhaust gases! Exhaust gases from internal combustion engines are harmful to your health. In particular, the soot particles contained in the diesel exhaust gas can cause cancer. When the internal combustion engine is running, there is a risk of poisoning from the CO, CH and NOx components contained in the exhaust gas.

  • Page 67: Overviews

    Overviews...

  • Page 68: General View

    Overviews General view General view 7312_003-172_V2 Lift mast Steering axle Overhead guard Drive axle Driver's compartment Fork arms Fuel tank Fork carriage Towing device Lift cylinders 174749 EN - 03/2017...

  • Page 69: Driver's Compartment

    Overviews Driver's compartment Driver's compartment 7314_003-048 Parking brake lever Cup holder for max. 0.5-l bottles Steering wheel Driver's seat Key switch Compartment and storage location for Display and operating unit operating instructions Document holder Accelerator pedal Operating devices for hydraulic and traction Brake pedal functions Steering column adjustment lever...

  • Page 70: Operating And Display Elements

    Overviews Operating and display elements Operating and display elements Display and operating unit 7314_003-043 Hazard warning system button Operating hours display Front windscreen wiper button Time display (digital) Working spotlight button Particle filter display Drive programme selector button Rotating beacon display Lighting button Interior lighting display Lighting symbol...

  • Page 71: Operating Devices For Hydraulic And Driving Functions

    Overviews Operating and display elements – If you have any questions, please contact your authorised service centre. Operating devices for hydraulic and driving functions Different versions of the operating devices are available for operating the truck's hydraulic and traction functions. The truck can be equipped with the following operating devices: •...

  • Page 72: Double Mini-Lever

    Signal horn button "Drive direction/turn indicator" cross lever NOTE Depending on the equipment, various electric attachment parts can be controlled via function keys (2) and (3). Changes must only be made by the STILL service centre. 174749 EN - 03/2017...

  • Page 73: Three-Way Mini-Lever

    "Drive direction/turn indicator" cross lever Signal horn button NOTE Depending on the equipment, various electric attachment parts can be controlled via function keys (2) and (3). Changes must only be made by the STILL service centre. 174749 EN - 03/2017...

  • Page 74: Four-Way Mini-Lever

    Signal horn button "Drive direction/turn indicator" cross lever NOTE Depending on the equipment, various electric attachment parts can be controlled via function keys (3) and (4). Changes must only be made by the STILL service centre. 174749 EN - 03/2017...

  • Page 75: Joystick 4Plus

    Overviews Operating and display elements Joystick 4Plus 6210_003-087 Horizontal rocker button for "3rd hydraulic LED for clamp locking mechanism (variant) function", tilt the lift mast Slider for the "4th hydraulic function", e.g. Pictograms for the basic hydraulic functions reach frame forwards/backwards Pictograms for the 5th hydraulic function and Vertical rocker button for the "drive direction"...

  • Page 76: Fingertip

    Right turn indicator button Drive direction switch Function key "5th function" NOTE Depending on the equipment, various electric attachment parts can be controlled via function keys (1) and (2). Changes must only be made by the STILL service centre. 174749 EN - 03/2017...

  • Page 77: Mini Console

    Overviews Operating and display elements Mini console The mini console is located on the steering column below the steering wheel. 7311_003-056 Travel direction switch Direction indicator switch 174749 EN - 03/2017...
  • Page 78 Overviews Operating and display elements 174749 EN - 03/2017...
