4. LAN SETUP

4.1 View the IP and MAC Addresses

When the module is running, the IP and MAC addresses can be viewed by following
these steps:
To view the IP address-
1. Run the discovery tool. It will detect the module and show its IP Address, Manufacturer
Name, Serial Number and Firmware Revision. IP address can also be read via a LAN
specific command
To view the MAC address-
1. There is a label on the cover of the module indicating the MAC address.
2. MAC address can also be seen on the "Home" page via a Web browser and can be
read via a LAN specific command.

4.2 LAN Reset

LAN reset can be done via a LAN specific command or via the front panel reset switch.
The default LAN settings are:
o DHCP enabled
o If DHCP fails to get a lease, auto-IP settings will be obtained.
o Hostname:
o Description:
o Controller Access
o Ping Server:
o Keep-Alive
o Auto-Negotiate:
o VXI-11 Discovery:
o Password:
o mDNS:
o DNS-SD:
HFE-LAN-last 3 digits of Serial Number.
TDK-LAMBDA HFE-LAN Last 3 digits of Serial Number.
One Client Only
Enabled
1800 Seconds (30 minutes)
Automatically select network speed
Enabled
None
Enabled
Enabled
