2. SPECIFICATIONS

2.1 GENERAL
When using the HFE LAN, the ratings and accuracies are the same as for the programming
and monitoring using PMBUS. Refer to the Instruction Manual for HFE power supply
(/S option) for the specifications and calculations.
2.2 ELECTRICAL
Ethernet
Auto-MDIX
Auto-Negotiate
2.3 NETWORK CONFIGURATION
MAC Address
IP Address
DHCP
Auto-IP
Static IP
Hostname
Duplicate IP Detection
Subnet Mask
Default Gateway
DNS Server
LAN Reset
2.4 LAN PROTOCOLS
TCP
IPv4
Instrument Protocols:
VXI-11
VISA
TCP Sockets
UDP Sockets
VXI-11 Discovery
Ping Server
HTTP
SNMP
2.5 COMMANDS
Meets IEEE 802.3u specifications
Accepts patch or cross-over cable connection
Selects fastest of 10Base-T or 100Base-T networks
(10 or 100 Megabits per second)
TDK-Lambda is assigned: 00:19:f9:xx:xx:xx
xx:xx:xx is the unique address for each unit
Can be detected with discovery tool
Discovery tool is available on
http://www.lxistandard.org/About/LXI-Discovery-Tools.aspx
IP can be changed via the Web Page or via SNMP
Get address from network server, leasing services.
Create own IP address: 169.254.xxx.xxx
xxx.xxx is created by the module.
Any IP fixed by the operator.
NetBIOS. Operator settable name.
Reject duplicate setting.
Mask set by DHCP or static
Address set by DHCP or static
Address set by DHCP
Reset configuration by front panel or a command
LAN packets follow Transmission Control Protocol
Internet Protocol version 4
Supports Core channel, not Abort or Interrupt channels
VXI-11 compliant, uses RPC and Port mapper.
Send commands to port 8003
Send commands to port 8005
Find connected instruments
Verify LAN connection to instrument
Web page server with Java scripts.
Collects and manages information of devices connected to
the network.
Control, Measurement and Status
(Refer to Section 8 for the full set)
