2.6 WEB PAGES
Multiple users
Identity
LAN Configuration
Active Control GUI
Send Commands
2.7 INDICATORS
Speed LED
Activity LED
LAN Status LED
Blink Identify
2.8 SWITCHES
LAN Reset
2.9 SECURITY
Web Page Password
Single Client Only
Block UDP Sockets
Disable VXI-11 Discovery
Disable Ping Server
COMPLIANCE
1 Operating Temperature
2 Storage Temperature
3 Operating Humidity
4 Storage Humidity
5 Vibration
6 Shock
7 Immunity
8 Weight
9 Size (W*H*D)
Specifications 5,6,7 in Table 3 are relevant only if the LAN module is installed in HFE1600/2500-
S1U racks
Maximum 2 web pages can be open at once
Identify power supply model, serial number, revision etc.
View and set LAN configuration
Program and read output settings
Send commands, read errors
Indicates the speed at which the communication is running.
Lit –100MBps.
Non Lit - 10MBps.
Indicates when LAN packets are detected.
Red/green, indicates module has valid IP connection
Find the LAN Module by remotely blinking the front panel LED
Reset LAN settings via front panel
Can set password to prevent unauthorized or accidental
changes to LAN module settings or suply settings
Set to prevent multiple programs from taking control
Single client will block attacks through UDP sockets
Stop intruders from finding the module
Stop intruders from finding the module
-10 ~ +70C
-30 ~ +85C
10~90% RH, no condensation
10~95% RH, no condensation
Built to meet IEC60068-2-64(Basic Transportation)
Built to meet IEC60068-2-27(Basic Transportation)
Built to meet IEC61000-4-2(Level 2,3), -3(Level 2), -4(Level 2),
-5 (Level 3,4), -6(Level 2), -8(Level 4), -11
Max 0.8 Kg
HFE1600 - 85 x 41 x 300mm
HFE2500 - 107 x 41 x 325mm
Table 3. Compliance
