HFE1600-S1U RACK INSTRUCTION MANUAL
HFE1600-S1U SERIES SPECIFICATIONS
1 Number of power supply modules
2 Maximum output power
3 Maximum output current
4 Input voltage / frequency range
5 Maximum input current (at 100/200Vac)
6 Maximum line regulation
7 Max load regulation
8 AC input connector
9 Output terminals
10 Remote sensing
11 Parallel operation
12 Series operation
Remote On/Off control
13
(INHIBIT)
Remote On/Off control
14
(ENABLE)
15 DC OK signal
16 AC fail signal
17 Over Temperature alarm signal
18 Output voltage trimming
19 Output voltage programming
20
Output voltage programming via I2C interface
21 Auxiliary power supply
22 Operating temperature
23 Storage temperature
24 Operating humidity
25 Storage humidity
26 Vibration
27 Shock
28 Applicable safety standards
29 Withstand voltage
30 Insulation resistance
31 Weight (Typ) (with accessories)
32 Size (W*H*D)
Notes:
*1 For cases where conformance to various safety standards (UL, EN etc.) is required, to be described as 100-240Vac (50/60Hz).
*2 Maximum voltage drop on load wires: HFE1600-12: 0.5V/wire, HFE1600-24,48: 1V/wire.
*3 Mixing of units with PMBus option ("HFE1600-xx/S") and standard units ("HFE1600-xx") is not allowed.
From 85~132Vac or 170~265Vac, constant load.
*4
From No-load to Rated load, constant input voltage. Measured at the sensing point in Remote sense.
*5
Maximum 5 units HFE1600 of the same output voltage rating (*3).
---
W
A
85~265Vac continuous, 47~63Hz, Single phase, separate input for each PS module.
(*1)
---
A
14.2/8.1 for each HFE1600 power supply module
%
(*4)
(*5)
%
Separate for each power supply. HFE1600-S1U: IEC inlet (C1 );
---
---
Two bus-bars outputs (two sides). Refer to outline drawing.
(*2)
V
---
---
Separate control for each PS unit, by electrical signal or dry contact.
---
OFF: 0~0.6V or short. ON: 2~15V or open.
Common for all PS units, by electrical signal or dry contact.
---
On: 0~0.6V or short. OFF: 2~15V or open.
Separate signal for each PS unit, open collector signal. Max.sink current: 10mA
---
Tracking, On when Vout>90+/-5% of set output voltage.
Separate signal for each PS unit, open collector signal. Max.sink current: 10mA
---
Separate signal for each PS unit, open collector signal. Max.sink current: 10mA
---
---
Common for all PS units, by built-in potentiometer. Refer to Instruction Manual.
Possible, Common for all PS units, by 0~5V signal. Refer to Instruction Manual.
---
---
Possible, Common for all PS units. Refer to Instruction Manual.
°C
11.2~12.5VDC. Maximum output current: 0.5A
°C
---
---
---
---
Built to meet IEC60068-2-64 (Basic Transportation)
Built to meet IEC60068-2-64 (Basic Transportation)
---
---
Input-Output: 3000Vac, 1min.
Input-Ground: 2000Vac, 1min.
---
Output-Ground: 48V model - 2250Vdc, 1min.
---
More than 100Mohm at 25°C and 70% RH. Output-Ground: 500Vdc
kg
---
445x43.6x365mm. Refer to Outline Drawing.
1
Refer to HFE1600 specifications
200A per output (Total 400A)
0.25%
0.80%
HFE 1600-S1U/TB: Terminal Block.
Possible. Refer to Instruction Manual.
Possible. Refer to Instruction Manual.
Possible. Refer to Instruction Manual.
On when 270Vac>Vin>85Vac.
Refer to Instruction Manual
-10~50°C: 100% load.
50°C to 60°C: Derate 2%/°C.
60°C to 70°C: Derate 2.5%/°C.
-30~85°C
10~90% RH, no condensation.
10~95% RH, no condensation.
UL60950-1, EN60950-1
12, 24V models - 500Vac, 1min
5.6
6

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HFE1600-S1U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for TDK-Lambda HFE1600-S1U

  • Page 1 6 Maximum line regulation (*4) 7 Max load regulation (*5) 0.80% Separate for each power supply. HFE1600-S1U: IEC inlet (C1 ); 8 AC input connector HFE 1600-S1U/TB: Terminal Block. 9 Output terminals Two bus-bars outputs (two sides). Refer to outline drawing.
  • Page 2: Regulatory Notices

    Marking by the CE Symbol indicates compliance to the EMC Directive and the Low Voltage Directive of the European Union. Such marking is indicative that the HFE1600-S1U rack meets the following technical standards: EN 55022:2006 /A1:2007 - ”Limits and Methods of Measurement of Radio Interference Characteristics of Information Technology Equipment.
  • Page 3: Safety Instructions

    ENERGY HAZARD The main output of HFE1600-S1U is capable of providing hazardous energy. Due to hazardous energy level the output bus bars and connections therefore must not be user accessible. Manufacturer’s final equipment must provide protection to service personnel...
  • Page 4: Overcurrent Protection

    A readily accessible branch circuit over current protective device rated 30A max. per each input must be incorporated in the building wiring. The protective device must disconnect both supply line simultaneously. FUSES There are no fuses in the HFE1600-S1U rack. SYMBOLS CAUTION Risk of Electrical Shock.
  • Page 5 Schutzfunktionen beeinträchtigt werden. TDK-Lambda ist nicht haftbar für Schäden, die durch Missachtung dieser Sicherheitsvorschriften entstehen können. Vorsicht Das HFE1600-S1U-Rack ist nicht für die Verwendung als kritische Komponente in nuklearen Steuerungssystemen, lebenserhaltenden Systemen oder Geräte für den Einsatz in gefährlichen Umgebungen, ohne die ausdrückliche schriftliche Genehmigung durch TDK- Lambda zugelassen Betriebsbedingungen und Umweltbedingungen Das HFE1600-S1U-Rack ist zur Installation gemäss Überspannungs-Kategorie 2 evaluiert worden.
  • Page 6 Sicherheits- und Warnsymbole VORSICHT Spannungsführende Teile-Gefahr durch elektrischen Schlag bzw. Energieinhalte. Handbuch-Symbol. Das Gerät bzw. Geräteteile warden mit diesem Symbol gekennzeichnet, wenn es für den Benutzer notwendig ist, sich auf die Anweisungen im Handbuch zu beziehen. Zeigt “spannungsführende Teile” mit gefährlicher Spannung an. Dieses Symbol weist auf das Vorhandensein einer heißen Oberfläche oder Komponente.
  • Page 7: Rear Panel Connections And Controls

    1. REAR PANEL CONNECTIONS AND CONTROLS Fig 1.1 Rear view of HFE1600-S1U series AC Line Inputs HFE 1600-S1U Address Selection Adjustment trimmer Output Bus Bars Output Bus Bars HFE 1600-S1U/TB AC Line Inputs 1.1. J1 Connector for Control and Monitoring Mating for J1 Control Plug (provided) or custom made plug/ cable should be inserted to J1 for proper HFE1600 rack operation.
  • Page 8 Table 1.1 Pin Allocation Chart Pin # Name Description Pos. # Control Referenced to plug J1 1,10 -SENSE Negative sense Connected to –LS for local sensing, or –V on Load side. Short Connected to Negative Output bus bar through 3 Ohm resistor. +SENSE Positive sense Connected to +LS for local sensing, or +V on Load side.
  • Page 9 SMB_ALERT 1.3. Output Bus Bar Connections The HFE1600-S1U has two identical Output Bus Bar connections on both sides of Rear Panel. They are connected in parallel in the Rack. Each of them or both can be used for output connections.
  • Page 10 1.5. PMBus address Each slot in the Rack (see fig-2.2) has its own address for PMBus communication Valid only if /S option power supply is being used. In case parallel connection of two racks is used, SW1 located at the rear panel is used to differentiate between addresses for the same slots. see Table 1.5.
  • Page 11 2.3 Keying Option to define the Rack’s Voltage Keying Option can be installed to ensure that only the correct Power Supply can be inserted into the Rack. The Key Option consists of two parts: Power Supply Key (one per unit Fig 2.3a) and Rack Keys (5 per Rack Fig 2.3b). Power Supply Key and Rack Keys should be fixed (by Flat head screws M3x6) in position corresponding to Output Voltage.
  • Page 12 2.5 Rack’s mounting options Rack can be mounted into 19” Rack Cabinet which suits both USA and European Standards: OPTION BRACKET IA705-32-15_ SEMS SCREW M5x10 2 PLACES MARKED "A" FIX OPTION BRACKET IA705-32-15_ TO THE RACK ASSEMBLY IA705-32-01-00_ OPTION BRACKET IA705-32-16ֹ...
  • Page 13: Typical Applications

    3. Typical applications 3.1 Basic connection For basic connection the supplied Control Plug should be inserted to J1. Fig 3.1 Basic connection diagram. 3.2 Remote sensing ATTENTION: 1. Maximum voltage drop on load wires: HFE1600-12: 0.25V/wire, HFE1600-24: 0.5V/wire, 48: 1V/wire. 2.
  • Page 14 3.4 Individual On/Off control for each PS Switch closed: Output OFF Switch open: Output ON Fig 3.4 individual units On/Off diagram. 3.5 Supervisory signals. Following signals are accessible from each power supply at J1: DC OK AC FAIL PS EXIST TEMP ALARM These signals are Open Collector type (max 15V, max 10mA), isolated from Output and referenced to SIGNAL RETURN.
  • Page 15: Signal Name

    3.7 Output Voltage programming by PMBus. Fig 3.7 Output Voltage programming by PMBus 3.8 PMBus Host connection To connect the rack to the Host computer connect communication cable (refer to table 3.8 for cable connection) between J2 and computer: Table 3.8 PMBus Cable. Signal Name From pin Wire (AWG)
  • Page 16 3.9 Parallel connection of two Racks To connect two Racks in parallel for higher Output Current: • Connect Main Outputs (Bus-Bars) in parallel. Make the connections as short as possible and with equal length. • Connect Senses (twisted pairs) to Load point. •...
  • Page 17 3.10 Series Rack connection Up to 2 racks with the same number of power supplies and rating (voltage and current) can be used to increase the output voltage. To connect two Racks in series: • Connect Main Outputs (bus bars) in series; •...
  • Page 18 HFE 1600 - S1U Outline Drawing...
  • Page 19 HFE 1600 - S1U-TB Outline Drawing...
