USER MANUAL
LAN Interface
For
HFE POWER SUPPLIES
with
PMBUS Option (/S)
Manual Supplement
Refer to HFE1600/2500 and HFE1600/2500-S1U Instruction Manual for installing
the power supplies, safety requirements and specifications.
IA817-04-01A
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HFE1600 and is the answer not in the manual?

Questions and answers

Related Manuals for TDK-Lambda HFE1600

Summary of Contents for TDK-Lambda HFE1600

  • Page 1 USER MANUAL LAN Interface HFE POWER SUPPLIES with PMBUS Option (/S) Manual Supplement Refer to HFE1600/2500 and HFE1600/2500-S1U Instruction Manual for installing the power supplies, safety requirements and specifications. IA817-04-01A...

  • Page 2: Table Of Contents

    Table of Content 1. GENERAL INFORMATION ................4 1.1 Introduction ............................4 1.2 Feature Summary ..........................4 1.3 Front Panel View ..........................8 2. SPECIFICATIONS ..................10 3. CONNECT TO NETWORK ................13 3.1 LAN Cable ............................13 3.2 Types of Networks ........................... 13 3.3 Power-up the LAN Module ......................14 3.4 IP Address ............................
  • Page 3 8. COMMAND SET ..................33 8.1 Selecting an Individual Power Supply ..................33 8.2 Selecting a Group of Power Supplies ..................33 8.3 Output On/Off ..........................33 8.4 Clear Faults ............................33 8.5 Programming the Output Voltage .................... 34 8.6 Programming the Current Limit (HFE2500/S only) ............. 34 8.7 Programming the Maximum allowed Programmable Output Voltage .......

  • Page 4: General Information

    Link and Activity LED on RJ-45 connector. r. LAN Status LED’s. *I2C Multi-drop Chain s. Allows connecting up to 16 power supplies (or housing of 2 racks of HFE1600-S1U/ TB or HFE2500-S1U/TB). t. One LAN IP address shared by all power supplies.
  • Page 5 HFE 1600 LAN Outline Drawing...
  • Page 6 HFE 2500 LAN Outline Drawing...
  • Page 7 IN / OUT Connector Pin Assignment HFE 1600 - LAN Connector Position Signal Names Description SIGNAL RETURN Return for PMBus signals: SCL, SDA, SMB ALERT MODULE EXIST Indicates that module is inserted into the shelf. “Active low” when connected to SIGNAL RETURN +12V AUX IN 12V DC Input referenced to SIGNAL RETURN.

  • Page 8: Front Panel View

    1.3 Front Panel View The module front panel, is shown below.      Figure 1. LAN Front Panel 1. LAN Connector: RJ45, 8 pin, 10/100MBps and IEEE802.3 compliant. 2. Link/Activity LED: This LED, embedded in the RJ-45 socket, glows green and blinks when the connection is made to an active network and packets are being transmitted.
  • Page 9 TDK Lambda shall not be liable for user’s failure to comply with these requirements. CAUTION: HFE1600/2500-LAN unit is not authorized for use as critical component in nuclear control systems, life support systems or equipment for use in hazardous environments without the express written approval of the managing director of TDK-Lambda.

  • Page 10: Specifications

    Auto-MDIX Selects fastest of 10Base-T or 100Base-T networks Auto-Negotiate (10 or 100 Megabits per second) 2.3 NETWORK CONFIGURATION TDK-Lambda is assigned: 00:19:f9:xx:xx:xx MAC Address xx:xx:xx is the unique address for each unit Can be detected with discovery tool IP Address Discovery tool is available on http://www.lxistandard.org/About/LXI-Discovery-Tools.aspx...
  • Page 11 Max 0.8 Kg Size (W*H*D) HFE1600 - 85 x 41 x 300mm HFE2500 - 107 x 41 x 325mm Table 3. Compliance Specifications 5,6,7 in Table 3 are relevant only if the LAN module is installed in HFE1600/2500- S1U racks...
  • Page 12 2.10 LAN Command Speed The following communication speeds are typical values only. In addition to the variability in the LAN interface, there are timing variations within the controller and the network routing. VISA Drivers Speed Commands and queries sent using VISA drivers generally take 10 mSec longer than the same message sent using TCP sockets.

  • Page 13: Connect To Network

    3. CONNECT TO NETWORK 3.1 LAN Cable The LAN cable must be supplied by the customer. It may be a standard straight “patch” CAT-5 (or better) network cable or it may be a “crossover” cable where the pins are reversed on one end.

  • Page 14: Power-Up The Lan Module

    3.3 Power-up the LAN Module The LAN module will automatically detect if it is connected to or disconnected from a network. It will also automatically look for a network server and receive or create an IP address. It will also broadcast its IP address and hostname to all other devices on the network.

  • Page 15: Hostname

    LAN computer. A custom hostname can be created through the web page (see section 5.5.2) or SNMP. For example, if the hostname is changed to “TDK-LAMBDA”, a control program can send a command to “TDK-LAMBDA”. The Hostname can be up to 15 characters. First character must be a letter. Last character must be a letter or digit.

  • Page 16: Lan Setup

    The default LAN settings are: DHCP enabled If DHCP fails to get a lease, auto-IP settings will be obtained. Hostname: HFE-LAN-last 3 digits of Serial Number. Description: TDK-LAMBDA HFE-LAN Last 3 digits of Serial Number. Controller Access One Client Only Ping Server: Enabled Keep-Alive...

  • Page 17: Web

    5. WEB PAGES Note – All figures in the web page section are examples only. 5.1 Benefit of Web Pages The HFE LAN web pages are useful for: • Reading the module’s model name, revision and LAN setup information • Configuring the LAN connection •...

  • Page 18: The Home Page

    5.3 The HOME Page The following page appears when the web page is first opened or when it is refreshed: Figure 4. HOME Page VISA Name Using IP Address: For automation programming, VISA is a type of communication driver. For LAN instruments, the IP address may be used in the VISA resource descriptor.

  • Page 19: Dc Power Page

    Power Supply is placed and the position of the DIP switch on the rear of the rack. Please refer to HFE1600-S1U and HFE2500-S1U user manuals for details on the slots and the DIP switch.
  • Page 20 Refresh List: When this button is clicked, the web page will make a scan to find connected HFE Power Supplies and put the discovered addresses into the list box. Every time the “DC Power” web page is opened, it will automatically scan for all connected Power Supplies and display it in the drop down menu.
  • Page 21 Please refer to HFE User Manual (/S option) for the range of Voltage and Current programming for each model (*1). In the case of HFE1600 supply, there is voltage programming only, so only the voltage setting will be seen in the Voltage/Current setting window.
  • Page 22 Faults Section This section displays the selected power supply’s Fault register. If any fault occurs, the “Fault” LED will lit. It will be required to scan all the supplies in the chain to check which of the supply has generated the fault. If the supply is found, the respective fault LED will be lit.
  • Page 23 This section can be used for programming a group of supplies. As soon as the supplies are selected from the drop down menu, they will appear in the box next to it. Click on “Set Group”. Select the operation – ON/OFF, Voltage or Current Setting or Max Voltage Setting.

  • Page 24: Lan Page

    (see section 3.5) or it may be changed in the LAN ➔ Configure ➔ Modify web page (section 5.5.2). Description: By default, this is “TDK-LAMBDA HFE-LAN last 3 digits of serial number”, but it may be changed in the LAN ➔ Configure ➔ Modify web page (section 5.5.2).
  • Page 25 Multicast DNS: Resolves Host Name to IP Address in networks that do not include a local server. By default, this is enabled. Modify: Click this button to open the window shown below 5.5.2 LAN ➔ Configure ➔ Modify Page If user is logged in, clicking the “Modify” button on the LAN ➔ Configure window, the following window appears.
  • Page 26 Fig 10. Static IP Settings Controller Access: Select the security feature for one client only or multiple clients. The multiple clients setting is needed to allow more than one controller connection at a time and to enable UDP socket connections. Multicast DNS: Enable or Disable the mDNS.
  • Page 27 LAN Keep-Alive: If you are logged in, this is how many seconds the web pages and all other protocols may be unused (idle) before the module automatically logs the user out. The default is 1800 seconds = 30 minutes. Range is 30-60000 sec. Ping Server: ‘Ping’...
  • Page 28 Agent variables that can be accessed. The MIB will be needed by any SNMP Host that wishes to communicate with the HFE LAN and can be retrieved from: https://uk.tdk-lambda.com/products/product-details.aspx?scid=304 HFE LAN utilizes four operations to respond to Host: Get, GetNext, Set and Trap G et –...
  • Page 29 Fig 14. SNMP Settings 5.5.6 LAN ➔ Users Page This page allows the user to create password protection for the web pages. There is no password protection for automation programming with VISA or sockets. By default, the “old password” is blank. The new password must be four or more characters long.

  • Page 30: Programming Using Visa Drivers

    6. PROGRAMMING USING VISA DRIVERS 6.1 VISA Description In the test and measurement industry, Virtual Instrument Software Architecture (VISA) is a popular framework that includes hardware drivers, configuration utilities and connection managers. A variety of communication busses are supported. VISA drivers are available from several instrument vendors.

  • Page 31: Programming Using Sockets

    7. PROGRAMMING USING SOCKETS 7.1 Socket Description The VISA drivers for the HFE LAN module with LAN are popular in the Test and Measurement world. However, some customers cannot use VISA because of installation or licensing issues or because the controller (i.e.: industrial PLC) does not have support for VISA. If you cannot use VISA drivers, then the HFE LAN offers socket connections.

  • Page 32: Input Buffer Requirements

    7.4 Input Buffer Requirements With a controller using TCP or UDP sockets, the module can receive commands much faster than it can process the commands. To make sure the HFE LAN is not overloaded, it is required that the controller sometimes sends a query and then waits for the response. The response is the acknowledgement from HFE LAN that it has finished processing all commands.

  • Page 33: Command Set

    8. COMMAND SET 8.1 Selecting an Individual Power Supply This command can be used to select an individual power supply from a group of supplies. If there is only 1 power supply in the entire chain, the command is not required. Syntax: INST:NSEL <xx>...

  • Page 34: Programming The Output Voltage

    Example: OUTP:PROT:CLE 8.5 Programming the Output Voltage This command sets the Voltage Limit. Syntax: VOLT<nn.nn> VOLT? Parameter: nn.nn. Please refer to HFE User Manual (/S option) for the range of Voltage programming for each model. Example: VOLT 46.5 Query: VOLT? Will return 46.5 in the example. Errors: SYSTEM:ERROR? May return: “Data out of range”...

  • Page 35: Output Voltage Monitoring

    Errors: SYSTEM:ERROR? May return: “Data out of range” Note: If Current programming is done, the above setting has to be at maximum. 8.8 Output Voltage Monitoring This query returns the measured voltage. Syntax: MEAS:VOLT? Example: MEAS:VOLT? May return 46.002 8.9 Output Current Monitoring This query returns the measured current.

  • Page 36: Enabling / Disabling The Monitoring Filter

    8.14 Inventory Details of the Power Supply 8.14.1 PMBUS Revision Syntax: SYST:VERS? Example: SYST:VERS? Will always return 1.1 8.14.2 Manufacturer Name Syntax: SYST:ID? Example: SYST:ID? Will always return TDK-LAMBDA 8.14.3 Model Name Syntax: SYST:MDL? Example: SYST:MDL? May return HFE1600-48/S 8.14.4 Nominal Output Syntax: SYST:XVM? Example: SYST:XVM? May return 48V 8.14.5 Software Revision...

  • Page 37: Inventory Details Of The Lan Module

    8.14.7 Manufacturing Date Syntax: SYST:DATE? Example: SYST:DATE? May return 12/12/2016 8.14.8 Serial Number Syntax: SYST:SER? Example: SYST:SER? May return DOD705BED0171W 8.15 Inventory Details of the LAN Module 8.15.1 Software Revision Syntax: SYST:COMM:LAN:VERS? Example: SYST:COMM:LAN:VERS? May return 1.28.18 8.15.2 Serial Number Syntax: SYST:COMM:LAN:SER? Example:...

  • Page 38: Troubleshooting

    9. TROUBLESHOOTING LAN Status LED Stays Red If LAN status LED stays red, then the module is not connecting to the network. Verify the LAN cable is connected to an active network. Look at the front panel link LED (part of the RJ-45 connector, see section 1.3) and verify it is green. If the LED is not lit, then the LAN cable is not connected properly.
