3.3 Power-up the LAN Module

The LAN module will automatically detect if it is connected to or disconnected from a
network. It will also automatically look for a network server and receive or create an IP
address. It will also broadcast its IP address and hostname to all other devices on the
network.
1. Insert the module into any slot of the HFE rack. The front panel LAN status LED will
initially be red.
2. The LAN cable may be connected before or after the module is inserted.
3. For a server network, wait about 10 seconds.
See that the front panel LAN Status LED turns green.
4. For a peer-to-peer network, wait about 60-90 seconds.
See that the front panel LAN Status LED turns green.
When the LAN Status LED turns green, the module has received an IP address.
Run the discovery tool to check the IP address received by the module.
If the LAN Status LED does not turn green, see troubleshooting section.
Note – There should be at least one HFE supply in the rack for the module to operate.

3.4 IP Address

The simplest and most reliable way to open a network connection is using the module's IP
address. This is a group of four numbers separated by periods (for example: 10.1.15.123).
This IP address may be viewed by running the discovery tool.
There are three modes by which the module can get an IP address, as show in this table:
IP Address DHCP
Mode Select DHCP is default after
"LAN Reset"
Assignment A s s i g n e d b y t h e
network server
Range
Any address
Lifetime
Address may change
as the DHCP server
assigns addresses
dynamically to many
instruments
Duplicate
Th e D H C P s e r ve r
Addresses s h o u l d
duplicate IP addresses
Table 4: Assignment of IP address by different Protocols
Auto-IP
Default after "LAN
Reset" if no DHCP
server is used
Assigned by the LAN
module.
169.254.xxx.xxx
Address may change
for the LAN module
Finds available auto-
p r e v e n t IP address
14
Static IP
May be set in the "LAN Modify"
web page (see section 5.5.2)
or by SNMP.
Assigned in the "LAN Modify" web
page (see section 5.5.2)
or by SNMP.
Any address
Fixed for the LAN module
Returns to original IP (before
change), LAN Status LED blinks.
If duplicate IP is detected at AC ON,
the IP defaults to DHCP or Auto-IP,
LAN Status LED blinks.
