Maintenance

Cleaning Your Garage Door

IMPORTANT: DO NOT USE A PRESSURE WASHER ON YOUR GARAGE DOOR!
While factory-applied finishes on garage doors are durable, it is desirable to clean them on
a routine basis. Some discoloration of the finish may occur when a door has been exposed
to dirt-laden atmosphere for a period of time. Slight chalking may also occur as a result of
direct exposure to sunlight.
Cleaning the door will generally restore the appearance of the finish. To maintain an aestheti-
cally pleasing finish of the garage door, a periodic washing of the garage door is recom-
mended.
THE FOLLOWING CLEANING SOLUTION IS RECOMMENDED:
A mild detergent solution consisting of one cup detergent (with less than 0.5% phosphate)
dissolved into five gallons of warm water will aid in the removal of most dirt.
NOTE: The use of detergents containing greater than 0.5% phosphate is not recommended
for use in general cleaning of garage doors.
NOTE: Be sure to clean behind weatherstrips on both sides and top of door.
CAUTION
NEVER MIX CLEANSERS OR DETERGENTS WITH BLEACH.
GLASS CLEANING INSTRUCTIONS
Clean with a mild detergent solution (same as above) and a soft cloth. After cleaning, rinse
thoroughly.
ACRYLIC CLEANING INSTRUCTIONS
Clean acrylic glazing with nonabrasive soap or detergent and plenty of water. Use your bare
hands to feel and dislodge any caked on particles. A soft, grit-free cloth, sponge or chamois
may be used to wipe the surface. Do not use hard or rough cloths that will scratch the acrylic
glazing. Dry glazing with a clean damp chamois.
NOTE: Do not use any window cleaning fluids, scouring compounds, gritty cloths or solvent-
based cleaners of any kind.

Painting Your Garage Door

Refer to Instruction Insert "Field Painting and Finishing Fiberglass or Steel Door Sec-
tions".
Maintaining The Finish
On Your Garage Door
If the factory finish is beginning to fade, the door may require a field applied top clear coat.
Depending on environment and usage, this may be necessary after 1 to 3 years of use. Refer
to Instruction Insert "Field Painting and Finishing Fiberglass Or Steel Door Sections".

Operation And Maintenance

OPERATING YOUR GARAGE DOOR...
Before you begin, read all warning labels affixed to the door and the installation instructions
and owner's manual. When correctly installed, your Wayne Dalton door will operate smoothly.
Always operate your door with controlled movements. Do not slam your door or throw your
door into the open position, this may cause damage to the door or its components. If your
door has an electric opener, refer to the owner's manual to disconnect the opener before
performing manual door operation below.
Manual door operation:
For additional information on manual garage door operations go to www.dasma.com and
reference TDS 165.
IMPORTANT: DO NOT PLACE FINGERS OR HANDS INTO SECTION JOINTS WHEN OPENING
AND/OR CLOSING A DOOR. ALWAYS USE LIFT HANDLES / SUITABLE GRIPPING POINTS
WHEN OPERATING THE DOOR MANUALLY.
Opening a Door: Make sure the lock(s) are in the unlocked position. Lift the door by using the
lift handles / suitable gripping points only. Door should open with little resistance.
Closing a Door: From inside the garage, pull door downward using lift handles / gripping point
only or a high friction area only. If you are unable to reach the lift handles/ suitable gripping
points only, use pull down rope affixed to the side of door. Door should close completely with
little resistance.
Using an electric operator:
IMPORTANT: PULL DOWN ROPES MUST BE REMOVED AND LOCKS MUST BE REMOVED OR
MADE INOPERATIVE IN THE UNLOCKED POSITION.
When connecting a drawbar (trolley type) garage door operator to this door, an drawbar
operator and or drawbar operator bracket must be securely attached to the top section of
the door, along with any struts provided with the door. Always use the drawbar operator and
or drawbar operator bracket supplied with the door. To avoid possible damage to your door,
Wayne Dalton recommends reinforcing the top section on models 8000, 8100, 8200 and
9100 doors with a strut (may or may not be supplied). The installation of the drawbar opera-
tor must be according to manufacturer's instructions and force settings must be adjusted
properly. Refer to the owner's manual supplied with your drawbar operator for complete
details on installation, operation, maintenance and testing of the operator.
MAINTAINING YOUR GARAGE DOOR...
Before you begin, read all warning labels affixed to the door and the installation instruc-
tions and owner's manual. Perform routine maintenance steps once a month, and have the
door professionally inspected once a year. Review your Installation Instructions and Owner's
Manual for the garage door. These instructions are available at no charge from Wayne Dalton,
a division of Overhead Door Corporation, P.O. Box 67, Mt. Hope, OH., 44660, or at www.
Wayne-Dalton.com. For additional information on garage door/operator maintenance go to
www.dasma.com and reference TDS 151, 167 and 179.
Monthly Inspections:
1. Visual Inspection: Closely inspect jambs, header and mounting surface. Any wood found
not to be structurally sound must be replaced. Inspect the springs, counterbalance lift cables,
track rollers, pulleys, rear back hangs and other door hardware for signs of worn or broken
parts. Tighten any loose screws and/or bolts. Check exterior surface of the door sections
for any minor cracks. Verify door has not shifted right or left in the opening. If you suspect
problems, have a trained door system technician make the repairs.
WARNING
GARAGE DOOR SPRINGS, COUNTERBALANCE LIFT CABLES, BRACKETS,
AND OTHER HARDWARE ATTACHED TO THE SPRINGS ARE UNDER
EXTREME TENSION, AND IF HANDLED IMPROPERLY, CAN CAUSE
SEVERE OR FATAL INJURY. ONLY A TRAINED DOOR SYSTEMS
TECHNICIAN SHOULD ADJUST THEM, BY CAREFULLY FOLLOWING THE
MANUFACTURER'S INSTRUCTIONS.
WARNING
NEVER REMOVE, ADJUST, OR LOOSEN THE BOLTS, SCREWS AND/OR
LAG SCREWS ON THE COUNTERBALANCE (END OR CENTER BEARING
BRACKETS) SYSTEM OR BOTTOM CORNER BRACKETS OF THE DOOR.
THESE BRACKETS ARE CONNECTED TO THE SPRING(S) AND ARE UNDER
EXTREME TENSION. TO AVOID POSSIBLE SEVERE OR FATAL INJURY,
HAVE ANY SUCH WORK PERFORMED BY A TRAINED DOOR SYSTEMS
TECHNICIAN USING PROPER TOOLS AND INSTRUCTIONS.
TorqueMaster Plus Springs: Pawl knob(s) (located on the TorqueMaster
®
the door) should be engaged to prevent the door from rapidly descending in case of spring
failure or forceful manual operation.
Torsion Springs: The torsion springs (located above the door) should only be adjusted by a
trained door systems technician. DO NOT attempt to repair or adjust torsion springs yourself.
Extension Springs: A restraining cable or other device should be installed on the extension
spring (located above the horizontal tracks) to help contain the spring if it breaks.
2. Door Balance: Periodically test the balance of your door. If you have a garage door
drawbar operator, use the release mechanism so you can operate the door by hand when do-
ing this test. Start with the door in the fully closed position. Lift the door to check its balance.
Adjust TorqueMaster or Extension spring(s), if door lifts by itself (hard to pull down) or if
®
door is difficult to lift (easy to pull down). DO NOT attempt to repair or adjust Torsion Springs
yourself. To adjust TorqueMaster or Extension spring(s), refer to your installation instructions
®
and owner's manual. If in question about any of the procedures, do not perform the work.
Instead, have it adjusted by a trained door systems technician.
3. Lubrication: The door should open and close smoothly. Ensure the door track rollers
are rotating freely when opening and closing the door. If track rollers do not rotate freely,
clean the door tracks, removing dirt and any foreign substances. Clean and lubricate (use a
non-silicon based lubricant) graduated end hinges, steel track rollers and bearings. DO NOT
lubricate plastic idler bearings, nylon track rollers, door track. DO NOT oil a cylinder lock, if
actuation is difficult use a graphite dust to lubricate.
18
end brackets above
®
