Bosch AEC-AMC2-UL1 Installation Manual page 16

16 en | Connections for Supporting UPS
Cables B and C - Battery Cables
1.
2.
3.
4.
5.
6.
2018-04 | AEC-AMC2-UL1 |
Connect the plug connector B1 on the PS-interface labeled
with BAT.
Attach connector B2b (red) to the + pin of the first
rechargeable battery.
With cable C connect the – pin of the first rechargeable
battery to the + pin of the second rechargeable battery.
Attach connector B2a (black) to the – pin of the second
rechargeable battery.
Stick the bracket (Fig. 1.2 – item J) on the back of the
housing next to the batteries.
Connectors B3a and B3b remain unused – fix them using
the bracket J.
AMC2 enclosure - 1 DIN
Bosch Access Systems GmbH
rail
