Mountain Buggy URBAN DOUBLE U2204 Instructions

Graco
model: SnugRide
IMPORTANT - KEEP FOR FUTURE REFERENCE
The stroller seat does not need to be removed to fit Carseat Clip.
These instructions are for the Carseat Clip that fits the SnugRide
car seat made by Graco only. This Carseat Clip fits the following
®
model strollers:
URBAN
DOUBLE U2204
TERRAIN
DOUBLE T2204
WARNING
• Check you have the Graco
Car Seat for this Carseat Clip.
• Do not use this Carseat Clip until you have
read and understood the instructions!
• Incorrect use can mean serious injury or death
to an infant!
• Do not use this Carseat Clip on any other
stroller as it may be unsafe.
• Never leave your child unattended.
• Check that car seat and Carseat Clip are secure
and cannot move forward, back, sideways or
upwards.
• Make sure infant is harnessed into the
car seat using the car seat manufacturer's
instructions.
• Do not leave baby in car seat (on or off stroller)
for long periods of time.
®
- Double/triple carseat clip instructions
®
URBAN
TRIPLE U3204
TERRAIN
TRIPLE T3204
model: SnugRide
®
infant
®
1. Temporarily Remove Sunhood
ALL MODELS
The sunhood wires need to be removed from sunhood joints to allow
Carseat Clip to be fitted. These wires are re-attached to stroller once
Carseat Clip has been fitted.
A
Sunhood Joint
B
1. Partial Seat Unfastening
®
ALL MODELS
Note: The Carseat Clip fits to right hand seat only. Left and right are
determined from pusher position.
X
A
STAGE 1
Pull support wire out of
1
sunhood joint A while
pushing against stroller frame
with other hand B. NB: This
operation is child proof and
therefore requires a degree
of force.
2 Repeat step (1) on other
side.
Fold sunhood back to rest on
3
handlebar.
STAGE 2
Unfasten fasteners (x) either side
1
of right-hand seat and peel fabric
back, exposing right-hand side
centre
bar
tube and centre bar.
Recline right-hand seat slightly.
2
URBAN
Loosen the strap beneath seat
3
at point A.
