Mountain Buggy Terrain Double Instructions

DOUBLE CARRYCOT INSTRUCTIONS
IMPORTANT, KEEP FOR FUTURE REFERENCE
These instructions are for Left and Right Carrycots which fit on the following model strollers:
WARNING
• Do not use this Carrycot until you have read and
understood the instructions!
• Carrycot is suitable for newborn baby to 6 months,
or until baby can sit unaided.
• Before placing baby into position check that the
Carrycot is secure and will not tip or fall.
• Baby must not be in the Carrycot when it is being
fastened or removed from the stroller frame.
• The depth from the top of the mattress to the top
of the side of the Carrycot at, or at any position
within 300mm/11.8in from the harness attachment
points, should not be reduced to less than 140mm/5.5in
when the mattress is in position. Mattress purchased
separately should conform to BS1877 part 10.
• Do not use accessories not designed for your stroller
as they may be unsafe.
• Do not use the Carrycot to transport children in a
motor vehicle.
• Never leave your child unattended.
The Sunhood and Seat(s) need to be removed from stroller be-
fore fitting Carrycot. To fit one Carrycot, remove one seat. To fit
two Carrycots, remove two seats. Make sure a left carrycot is
fitted to left side, and a right to right side. Left and right are deter-
mined when standing behind stroller, in the pushing position.
Store items removed in a dry safe place.
Terrain Double - T2204-000 Urban Double - U2204-000
Removing Sunhood
Standing beside stroller and
1
using a degree of force, pull sunhood
support wire towards you by about
50mm/2in.
Unfasten sunhood fabric from the stroller frame and seat near handle bar.
3
Removing Seat
centre bar
A
Unfasten seat from frame along
1
side tubes and centre bar.
2 Unfasten strap underneath seat
at point A (does not apply to
Terrain models).
AMDCis1/8/02gen
1
2
2 Remove support wire 1 from
the plastic joint 2 on the side
nearest to you.
Then remove wire from the plastic
joint on other side.
right
left
seat
seat
seat
support
wire
B E
C D
Push seat forward, then slide
3
fabric off seat support wire.
Remove seat support wire from
4
stroller frame at B,C,D & E.
