SINGLE CARRYCOT INSTRUCTIONS
IMPORTANT, KEEP FOR FUTURE REFERENCE
These instructions are for the Single Carrycot which fits the following model strollers:
Terrain Single - T1204-000
WARNING
Do not use this Carrycot until you have read and un-
derstood the instructions!
Carrycot is suitable for newborn baby to 6 months, or
until baby can sit up unaided.
Before placing baby into position check that the
Carrycot is secure and will not tip or fall.
Baby must not be in the Carrycot when it is being
fastened or removed from the stroller frame.
The depth from the top of the mattress to the top of
the side of the Carrycot at, or at any position within
300mm/11.8in from the harness attachment points,
should not be reduced to less than 140mm/5.5in when
the mattress is in position. Mattress purchased
separately should conform to BS1877 part 10.
Do not use accessories not designed for your stroller
as they may be unsafe.
Do not use the Carrycot to transport children in a
motor vehicle.
Never leave your child unattended.
The Sunhood and Seat need to be removed from the stroller before
fitting the Carrycot. Store items removed in a dry safe place.
Removing Sunhood
All Models
Standing beside stroller and
1
using a degree of force, pull sunhood
support wire towards you by about
50mm/2in.
Unfasten sunhood fabric from the stroller frame and seat near handle
3
bar.
Urban Single - U1204-000
1
2
2
Remove support wire 1 from
the plastic joint 2 on the side
nearest to you.
Then remove wire from the plastic
joint on other side.
Rollerbug Single - R1204-000
Removing Seat
All Models
A
Unfasten seat from frame along
1
side tubes.
2
Unfasten strap underneath seat at
point A (does not apply to Terrain
models).
Support brackets for Carrycot are different for each
model, except Rollerbug and C:drive use the same brack-
ets. Check label on the bracket to ensure you have the
correct bracket(s) for your model stroller.
2
1
AMSCis1/8/02gen
C:drive Single - C1204-000
seat
support
wire.
B C
Push seat forward, then slide
3
fabric off seat support wire.
Remove seat support wire
4
from stroller frame at B and C.
3
3
4
