Mountain Buggy Terrain Instructions

SINGLE CARRYCOT INSTRUCTIONS
IMPORTANT, KEEP FOR FUTURE REFERENCE
These instructions are for the Single Carrycot, which fits the following
model strollers:
Terrain Single - T1204
WARNING
• Do not use this Carrycot until you have read and
understood the instructions!
• Carrycot is suitable for newborn baby to 6 months, or
until baby can sit up unaided.
• Before placing baby into position check that the
Carrycot is secure and will not tip or fall.
• Baby must not be in the Carrycot when it is being
fastened or removed from the stroller frame.
• The depth from the top of the mattress to the top of
the side of the Carrycot at, or at any position within
300mm/11.8in from the harness attachment points,
should not be reduced to less than 140mm/5.5in when
the mattress is in position. Mattresses purchased
separately should conform to BS1877 part 10.
• Do not use accessories not designed for your stroller
as they might be unsafe.
• Do not use the Carrycot to transport children in a
motor vehicle.
• Never leave your child unattended.
• Sunhood and seat need to be removed from stroller before fitting Carrycot.
• Store items removed in a dry safe place.
Urban Single - U1204
STAGE 1
Removing Sunhood
Sunhood Joint
A
B
1
Removing Seat
Unfasten seat from frame along
1
side tubes.
2 Unfasten strap underneath seat
at point A (does not apply to Terrain
model).
ASCis1/3/04gen
(both models)
Pull support wire out of
1
sunhood joint A. This
operation is child proof and
therefore requires a degree of
force. To assist in pulling
support wire out, push
against buggy frame with other
hand B.
Repeat step (1) on other
2
side.
Unfasten sunhood fabric
3
from stroller frame and seat
near handle bar.
Push seat forward, then slide
3
fabric off seat support wire.
4 Remove seat support wire
from stroller frame at B and C.
