Meter Description

LCD Description

Find Quality Products Online at:
1. Air Velocity vane
2. Type K Temperature probe input
3. LCD Display
4. ON/OFF Power button
5. Backlight and▲ button
6. MODE button
7. Unit Button
8. SET and▼ button
9. RECORD button
10. Hold Button
1. Air Velocity
2. Record
3. Max
4. Min
5. Hold
6. Air Flow
7. Battery Indicator
8. Auto Power OFF
9. Unit of Measure
10. Temperature Units
11. Lower LCD Display
12. Upper LCD Display
13. Type K Temperature
