MODEL: MX515SPBI (DYM1588SD)
COBRA LAWN MOWER
OWNER'S MANUAL
WARNING!
When using the machine the safety rules must be followed. For your own safety and bystanders please read these
instructions before operating the machine. Please keep the instructions safe for later use.
Cobra Garden Machinery
Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK
www.cobragarden.co.uk
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MX515SPBI and is the answer not in the manual?

Questions and answers

Related Manuals for Cobra MX515SPBI

Summary of Contents for Cobra MX515SPBI

  • Page 1 MODEL: MX515SPBI (DYM1588SD) COBRA LAWN MOWER OWNER’S MANUAL WARNING! When using the machine the safety rules must be followed. For your own safety and bystanders please read these instructions before operating the machine. Please keep the instructions safe for later use.
  • Page 2 WARNING： For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions can result in serious personal injury. Spend a few moments to familiarize yourself with your mower before each use. Keep this manual in a safe place, so that the information is available at all times. If you give the equipment to any other person, hand over these operating instructions and safety regulations as well.

  • Page 3: Table Of Contents

    CONTENTS SECTION 1 SYMBOLS MARKED ON THE PRODUCT……………………………4 SECTION 2 GENERAL SAFETY RULES…………………………………………… 4 SECTION 3 PARTS DESCRIPTION………………………………..…………….…. 7 SECTION 4 TECHNICAL DATA…………………………………………………...…. 7 SECTION 5 ASSEMBLY…………………………………………………………….… 8 SECTION 6 “3 IN 1”……………………………………………………………….…... 10 SECTION 7 OPERATION INSTRUCTIONS……………………………………..…. 11 SECTION 8 MAINTENANCE INSTRUCTIONS ……………………………..…….

  • Page 4: Symbols Marked On The Product

    WARNING： For your own safety please read this manual before attempting to operate your new unit. Failure to follow instructions can result in serious personal injury. Spend a few moments to familiarize yourself with your mower before each use. 1. SYMBOLS MARKED ON THE PRODUCT(on the rear cover) Fig.
  • Page 5 ●Keep in mind that the operator or user is responsible for accidents or hazards occurring to other people or their property. ●The operators must receive proper training in the use, adjustment and operation of the machine, including prohibited operations. Preparation ●...
  • Page 6 ● Stop the engine and disconnect the spark plug wire, make sure that all moving parts have come to a complete stop and, where a key is fitted remove the key: - before clearing blockages or unclogging chute. - before checking, cleaning or working on the lawn mower. - after striking a foreign object.

  • Page 7: Parts Description

    16. Brake control handle 5. Locking Lever 11. Fuel cap 17. Mulching wedge 6. Grass catch bag 12. Oil Cap 18. Discharge channel 4. TECHNICAL DATA Model MX515SPBI Engine type Briggs 675IS Self-Propelled Engine Displacement 163cm³ Nominal Power 2.5kW Blade Width...

  • Page 8: Assembly

    MX515SPBI Guaranteed Sound pressure level 84.9dB (A) at the operator’s position [k=3 dB (A)] (According to EN ISO 5395-1 Annex F & EN ISO 5395-2, EN ISO 4871) Measured sound power level 94.1dB (A) k=2.04 dB (A) Guaranteed Sound Power level...
  • Page 9 Fig.2 5.3 MOUNTING AND DISMOUNTING THE GRASS CATCHER 1. To fit: Raise the rear cover and hitch the grass catcher on rear of mower. (Fig. 3A) (Fig.3B) 2. To remove: grasp and lift rear cover, remove grass catcher. Fig. 3A Fig.

  • Page 10: In 1

    6. “3 in 1” Collection, Mulch and Side Discharge The MX515SPBI lawn mower offers the facility to collect grass, mulch or provide side grass side discharge: Grass mulching tips: The method of mulching grass clippings involves cutting the clipped grass more than once into smaller pieces of grass. The finely chopped grass makes an ideal fertilizer for the lawn.

  • Page 11: Operation Instructions

    THREE: Mowing with the grass catcher bag 1. For mowing with the grass bag, remove the mulching wedge, the side discharge chute and mount the grass bag. 2. Removing the mulching wedge. -Lift the rear cover and remove the mulching wedge. -Removing the discharge chute: WARNING: Stop the engine and ensure the blade is stopped first! 3.
  • Page 12 Start the engine carefully according to instructions and with feet well away from the blade. Do not tilt the lawn mower when starting the engine. Start the mower on a level surface, free of high grass or obstacles. Keep hands and feet away from the rotating parts. Do not start the engine when standing in front of the discharge opening. 7.3 OPERATION PROCEDURES During operation, tightly hold the brake handle with both hands.
  • Page 13 underside of the deck preventing proper mowing of the grass clippings. Cut no more than 1/3 the length of the grass. The recommended cut for mowing is 1/3 the length of the grass. Ground speed will need to be adjusted so the clippings can be dispersed evenly into the lawn.

  • Page 14: Maintenance Instructions

    8. MAINTENANCE INSTRUCTIONS SPARK PLUG Use only original replacement spark plug. For best results, replace the spark plug every 100 hours of use. BRAKE PADS Check and/or replace the engine brake pads in service agent regularly, only original parts can be used as replacement. 9.
  • Page 15 Replace with an approved factory replacement blade only. Possible damage resulting from blade unbalance condition is not the responsibility of the manufacturer. When you change the blade, Must use the original type marked on the blade (Cobra 263001679) 10.4 ENGINE Refer to the separate engine manual for engine maintenance instructions.

  • Page 16: Storage Instructions (Off Season)

    Fig.15A Fig.15B Start the engine carefully according to instructions and with feet well away from the blade. Do not tilt the lawn mower when starting the engine. Start the mower on a level surface, free of high grass or obstacles. Keep hands and feet away from the rotating parts.

  • Page 17: Trouble Shooting Guide

    12 TROUBLES SHOOTING PROBLEM PROBABLE CAUSE CORRECTIVE ACTION Engine does not Instart battery is not charged Charge the battery with the charger start. Fuel tank is empty. Fill tank with fuel: refer to ENGINE OWNERS MANUAL. Air cleaner element is dirty. Replace the air cleaner element: refer to ENGINE OWNERS MANUAL Spark plug loose.

  • Page 18: Warranty

    Please Register Your Mower If your dealer did not collect registration information from you, please take a few minutes and register your purchase with Cobra. You can register by completing and mailing the registration card that should be in the box or by going online to: www.cobragarden.co.uk and clicking on Product Registration.

  • Page 19: Ec-Declaration Of Conformity

    15. EC-DECLARATION OF CONFORMITY EC Declaration of Conformity We herewith declare, Cobra Garden Machinery, Henton & Chattell Ltd, London Road, Nottingham NG2 3HW United Kingdom That the following machine complies with the appropriate basic safety and health requirements of the EC Directive based on its design and type, as brought into circulation by us.
