MODELS: M40B M40SPB M46B M46SPB
COBRA LAWN MOWER
OWNER'S MANUAL
Cobra Garden Machinery
Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK
www.cobragarden.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M40B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cobra M40B

Summary of Contents for Cobra M40B

  • Page 1 MODELS: M40B M40SPB M46B M46SPB COBRA LAWN MOWER OWNER’S MANUAL Cobra Garden Machinery Henton and Chattell Ltd., London Road, Nottingham NG2 3HW UK www.cobragarden.co.uk...

  • Page 2: Table Of Contents

    CONTENTS SECTION 1 SYMBOLS MARKED ON THE PRODUCT...........3 SECTION 2 GENERAL SAFETY RULES..............3-5 SECTION 3 PARTS DESCRIPTION...............5-9 SECTION 4 TECHNICAL DATA................9-10 SECTION 5 ASSEMBLY..................10-13 SECTION 6 3 IN 1……..................13-14 SECTION 7 OPERATION INSTRUCTIONS ............14-18 SECTION 8 MAINTENANCE INSTRUCTIONS…………………………………..…18 SECTION 9 LUBRICATION..................19 SECTION 10 CLEANING..................19-20 SECTION 11 STORAGE INSTRUCTIONS (OFF SEASON)……………………...20-21 SECTION 12 TROUBLESHOOTING……………………………………………..….21...

  • Page 3: Section 1 Symbols Marked On The Product

    WARNING： For your own safety please read this manual before attempting to operate your new mower. Failure to follow instructions can result in serious personal injury. Spend a few moments to familiarise yourself with your mower before each use. 1. SYMBOLS MARKED ON THE PRODUCT Fig.
  • Page 4 Training 1. Before using the lawnmower read the instructions carefully. Familiarise yourself with the controls and pay particular attention in learning how to stop the machine in an emergency. 2. Never allow children or people unfamiliar with these instructions to use the lawn mower. Local regulations can restrict the age of the operator.
  • Page 5 16. Do not start the engine when standing in front of the discharge chute. 17. Never put hands or feet near or under rotating parts. Keep clear of the discharge opening at all times. 18. Always ensure the engine is fully switched off before picking up/carrying the Lawnmower. 19.

  • Page 6: Section 3 Parts Description

    10. Spark plug 11. Fuel cap 12. Cable clamp Throttle choke Lever 14. Brake control handle Including A: Spark plug wrench 4. TECHNICAL DATA Model M40B M40SPB M46B M46SPB Engine type Briggs 450E Briggs 450E Briggs 450E Briggs 500E Self Propelled...

  • Page 7: Section 5 Assembly

    5. ASSEMBLY 5.1 FOLDING HANDLE 1. Fix the lower handlebars into the unit body with a suitable spanner. (Fig.2F) 2. Lift the two locking levers to release the upper handlebars for folding. 3. Push the locking lever closed or tighten the knobs to lock the handlebars in the operating position. (Fig.2G/Fig.2H) 4.
  • Page 8 5.3 STARTER HANDLE Move the starter handle from the engine to the rope guide. Fig.4 5.4 HEIGHT OF CUT Apply outward pressure to disengage lever from rack. Move lever forward or back to adjust height. (see clause 7.9) Fig.5C 7. OPERATING INSTRUCTIONS 7.1 BEFORE STARTING Service the engine with petrol and oil as instructed in the separate engine manual packed with your mower.
  • Page 9 7.2 TO START ENGINE AND ENGAGE BLADE -Always check the engine oil level before starting. Refer to the engine manual. 1. The unit is equipped with a rubber boot over the end of the spark plug, make certain the metal loop on the end of the spark plug wire (inside the rubber boot) is fastened securely over the metal tip on the spark plug.
  • Page 10 7.5 USING THE POWER DRIVE FUNCTION (M40SPB & M46SPB) – Self Propelled Mowers Only Grip the Self-drive control handle, the lawnmower will move forward automatically with a speed of about 3.6 km/h. Release the self-drive handle and the lawnmower will stop moving. Fig.10 CAUTION: your mower is designed to cut normal residential grass of a height no more than 250mm.

  • Page 11: Section 8 Maintenance Instructions

    7.8 DECK The underside of the mower deck should be cleaned after each use to prevent a buildup of grass clippings, leaves, dirt or other matter. If this debris is allowed to accumulate, it will invite rust and corrosion, and may prevent proper mulching. The deck may be cleaned by tilting the mower and scraping clean with a suitable tool (make certain the spark plug wire is disconnected).
  • Page 12 When you change the blade, use the original type marked on the blade: Cobra part number 26300100401 for M40B and M40SPB Cobra part number 263001465 for M46B and M46SPB Please contact your local dealer for the supply of genuine Cobra parts WARNING: Do not touch rotating blade.

  • Page 13: Section 11 Storage Instructions (Off Season)

    10.4 ENGINE Refer to the separate engine manual for engine maintenance instructions. Maintain engine oil as instructed in the separate engine manual packed with your unit. Read and follow the engine instructions carefully. Service the air filter as per the separate engine manual. Clean every few hours under extremely dusty conditions. Poor engine performance and flooding usually indicates that the air filter requires attention.

  • Page 14: Section 12 Troubleshooting

    12. TROUBLESHOOTING PROBLEM PROBABLE CAUSE CORRECTIVE ACTION Engine does not Throttle choke not in the correct position Move throttle choke to the correct position start. for the prevailing conditions. Fuel tank is empty. Fill the tank with fuel: refer to the ENGINE MANUAL. Air filter element is dirty.

  • Page 15: Section 13 Warranty

    Any damage that occurs from the use of non-genuine Cobra parts will not be covered. We reserve the right to reject any claim where the purchase cannot be verified or when it is clear that the product was not maintained properly.
  • Page 16 In case of alteration of the machine, not agreed upon by us, this declaration will lose its validity Machine Description: Lawn Mower Machine Types: M40B (1563N) M40SPB (1564N) M46B (1565N) M46SPB (1566N) Displacement: 125 cm Max. Cutting length: 400 mm - M40B (1563N) M40SPB (1564N)
