TABLE OF CONTENTS
Page
LIST OF ILLUSTRATIONS ..... . .. . . .. .... . . ii
LIST OF TABLES ... .. . . . . . . . . . .... . .. . ... . .
Secti on 1 Specification . . . . . . . . . . . . . . . . .. 1-1
Section 2 Operating Instructions 2-1
I
WA RNING
I
THE FOLLOWING SERVICE INSTRUCTIONS ARE
FOR USE BY QUALIFIED PERSONNEL ONLY. TO
AVOID PERSONAL INJURY, DO NOT PERFORM
ANY SERVICING OTHER THAN THA T
CONTAINED IN OPERA TlNG INSTRUCTIONS
UNLESS YOU ARE QUALIFIED TO DO SO.
Section 3 Theory of Operation. . . . . . . . . . . . . 3-1
Section 4 Calibration Procedure . . . . . . . . . . .. 4-1
Performance Check . . . . . .. . .. . 4-3
Adjustment Procedure . . . . ... .. 4-12
Section 5 Maintenance ... .. . . . . . . . . . ... . 5-1
Section 6 Options .... .... .. . . . . . . . . . . . . 6-1
Section 7 Replaceable Electrical Parts
. .. . .. . 7-1
Section 8 Diagrams and Illustrations ... .. .... 8-1
Section 9
Replaceable Mechanical Parts . . . .. . 9-1
@
