.HOLIDAY.–.Holiday.configuration
No. Status
1 0-12
2 0-31
3 0-99
*Depends on the selected language (English by default).
.BROCASTS.–.Broadcast.configuration
No. Status
1 0 to 2
OAT Broadcast
2 0 to 239
3 0 to 239
4 disable/enable
Daylight Savings Select – Summer time (entering)
5 1 to 12
6 1 to 7
7 1 to 5
Daylight Savings Select – Winter time (leaving)
8 1 to 12
9 1 to 7
10 1 to 5
*Depends on the selected language (English by default).
..DATETIME.–.Date/Time.configuration
No. Status
Date (DD/MM/YY)
1 1 to 31
2 1 to 12
3 0 to 99
4 Monday-Sunday
Time (HH:MM)
5 0 to 24
6 0 to 59
Daylight Saving Time
7 no/yes
8 no/yes
9 no/yes
10 no/yes
*Depends on the selected language (English by default).
.CTRL_ID.–.Control.ID.configuration..........................
No. Status
1 0 to 239
2 0 to 239
3 9600/19200/38400
4 -
5 -
6 -
7 -
*Depends on the selected language (English by default).
Default Displayed text*
0 Holiday Start Month
0 Start Day
0 Duration (days)
Default Displayed text*
2 Activate
0 Bus
0 Element
disable Daylight Savings Select
3 Month
7 Day of Week (1=Monday)
5 Week Number of Month
10 Month
7 Day of Week (1=Monday)
5 Week Number of Month
Default Displayed text*
- Day of month
- Month of year
- Year
- Day of Week
hour Hour
min Minute
- Daylight sav. time on
- Daylight sav. time off
- Tomorrow is a holiday
- Today is a holiday
Default Displayed text*
0 CCN Element Number
1 CCN Bus Number
9600 CCN Baud Rate
30XAXW Touch Pilot Device Description
Location Description
ECG-SR-20M47010 Software Part Number
Serial Number
Description
Holiday start month
Holiday start day
Holiday duration (days)
Description
Not applicable
Bus number of the unit with outdoor temperature sensor
Element number of the unit with outdoor temperature sensor
Summer/winter time activation (daylight saving selection)
Month
Day of the week (1 = Monday)
Week of the month
Month
Day of the week (1 = Monday)
Week of the month
Description
Day of the month
Month
Year
Day of the week
Hour
Minutes
Daylight saving time active
Daylight saving time inactive
The following day is a holiday
The present day is a holiday
Description
Element number
Bus number
Communication speed
Unit description
Location description: The number corresponds to the country
Software version
Serial number (MAC address)
