Roscoe Medical TENS 7000 To Go Quick Reference Instructions

QUICK REFERENCE GUIDE
Top
Front
7
8
6
BELT

ELECTRODES

LEAD WIRES

SNAP WIRES

For more information about your TENS 7000 To Go™ unit, visit us online at roscoemedical.com or call 1-800-871-7858.
The purpose of this guide is to assist you in correctly operating your TENS 7000 To Go™ unit.
Do not use this device for undiagnosed pain symptoms until consulting a physician. This guide
is not intended to replace or substitute the TENS 7000 To Go™ Instruction Manual. PLEASE READ
THE INSTRUCTION MANUAL COMPLETELY BEFORE USING THIS DEVICE.
practice the contraindications, warnings, cautions and operating instructions found on pages 4 – 5 of your
instruction manual. Always follow the operating instructions prescribed by your healthcare provider.
2
1
4
3
5

SPECIAL FEATURES

The belt feature of the TENS 7000 To Go™ allows
patients to comfortably apply stimulation to the lower
back without having to contort or twist into positions
commonly associated with the placement of self-
adhesive electrodes. The belt fits comfortably under
clothes and the belt clip ensures continued mobility.
The TENS 7000 To Go™ features two protective covers
SPRAY
that prevent unintentional changes to settings.
Turn on device by rotating the dial clockwise and
select the desired intensity level. Turn off
device by turning dial counterclockwise to O.
Low battery indicator
low. Replace battery when stimulation feels weaker.
Side
9
10
signals when battery is
Read, understand and
TENS 7000 TO GO
UNIT
1

Lead connector sockets - 2 channels

2
On / off / intensity dial - 2 channels
3
Panel cover with reference guide
4

Liquid crystal display (LCD)

5

Mode selection button

6

Set selection button

7
Increment control / increase button
8
Increment control / decrease button
9
Protective cover
10
Belt clip
TENS 7000 to Go DT6070
replacement parts :
GB7000 – Conductive Back Belt
WS3147 – Snap Wires
WW3005 – Lead Wires
TA9050 – Battery

INSERT BATTERY

Press arrow and slide
battery compartment
cover open. Insert 9V
battery, matching the
+ and – ends to
those in unit.
The battery should
be place on top of the
compartment ribbon
to allow easy battery
removal.
PAGE 1
™
