QUICK REFERENCE GUIDE
The purpose of this guide is to assist you in correctly operating your InTENSity™ Micro Combo unit. This
device should only be used under the continued supervision of a healthcare professional. This guide is
not intended to replace or substitute the InTENSity™ Micro Combo Instruction Manual. PLEASE READ
THE INSTRUCTION MANUAL COMPLETELY BEFORE USING THIS DEVICE. Read, understand and practice
the contraindications, warnings, cautions and operating instructions found on pages 7 – 12 on your
instruction manual. Always follow the operating instructions prescribed by your healthcare provider.
1
Top
5
3
4
Front
ELECTRODES
(SET OF 4)
LEAD WIRES
(2 SETS)
For more information about your InTENSity™ Micro Combo unit, please visit roscoemedical.com or call 1-800-871-7858.
2
6
7
8
9
10
Back
DEFINITIONS
TENS
Transcutaneous
Electrical
Nerve Stimulator
MIC
Microcurrent
Do not use this
device for
undiagnosed pain
syndromes until
consulting
a physician.
11
13
12
INDICATION FOR USE
The TENS and MIC modes are often prescribed for:
• Symptomatic relief of chronic pain
• Post traumatic pain
• Post surgical pain
TENS is a non-invasive, drug-free method of controlling pain
that uses tiny electrical impulses sent to the nerves to modify
your perception of pain. TENS does not cure any physiological
problem; it only helps control pain.
MIC stimulation consists of a very low current sent into the
cells of the body. The current is so faint it is measured in
millionths of an amp (or microamps) and is often not felt by
the user. MIC increases energy production in cells of your body
and increases tissue healing rates.
PAGE 1
INTENSITY
™
MICRO COMBO UNIT
1 Channel 1 output socket
2 Channel 2 output socket
3
Channel 1 intensity increase button
4 Channel 1 intensity decrease button
5 Mode (M) selection button
6
LCD display
7 Parameter (S) selection button
8 Channel 2 intensity increase button
9
Channel 2 intensity decrease button
10 Power on/off button
11 Belt clip
12
Battery compartment cover
13 AC/DC adapter receptacle
InTENSity MICRO COMBO
™
replacement parts:
WW3005 – lead wires
EIF1515TC2 – electrodes
