EtherWAN EM1100 User Manual

Gigabit ethernet media converter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual

FCC Statement

The FCC (Federal Communications Commission) restricts the amount of
radio frequency emission and radiation coming from computer equipment.
The equipment introduced in this manual has been tested and found to
comply with the limits for a Class A digital device pursuant to Part 15 of
the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment.
This equipment generates, uses, and can radiate radio frequency energy,
and if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause
harmful interference in which case the user is required to correct the
interference at his/her own expense.
Any changes or modifications not expressly approved by the manufacture
would void the user's authority to operate the equipment.

Trademarks

Product names mentioned in this manual may be trademarks or registered
trademarks of those products.
All trademarks or brand names mentioned are properties of their respective
companies.

Preface

This manual describes how to install and use the Gigabit Ethernet Media
Converter. The Converter introduced here provides one channel media
conversion solution:
10/100/1000Base-TX ↔ 1000Base-SX/LX
1000Base-SX/LX ↔ 100Base-FX
The Gigabit Ethernet Media Converter fully complies with IEEE802.3
10Base-T, IEEE802.3u 100Base-TX/FX, IEEE802.3ab 1000Base-T, and
IEEE802.3z 1000Base-SX/LX Ethernet standards.
In this manual, you will find:
Product overview
Features on the media converter
Illustrative LED functions
Installation instructions
Specifications
User's Manual
Gigabit Ethernet Media Converter
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EM1100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for EtherWAN EM1100

Summary of Contents for EtherWAN EM1100

  • Page 1: Fcc Statement

    Gigabit Ethernet Media Converter FCC Statement The FCC (Federal Communications Commission) restricts the amount of radio frequency emission and radiation coming from computer equipment. The equipment introduced in this manual has been tested and found to comply with the limits for a Class A digital device pursuant to Part 15 of the FCC rules.

  • Page 2: Table Of Contents

    Table of Contents FCC S ..............1 TATEMENT ................1 RADEMARKS ...................1 REFACE ..............2 ABLE OF ONTENTS ................3 NTRODUCTION ...........3 RODUCT VERVIEW ...........4 RODUCT EATURES ..............4 ACKING ........4 HANNEL EDIA ONVERTER ............4 HYSICAL ORTS ............4 TATUS .................6 NSTALLATION .......6 ELECTING A ITE FOR THE QUIPMENT ..........6 ONNECTING TO...

  • Page 3: Introduction

    Gigabit Ethernet Media Converter Introduction The Gigabit Ethernet Media Converter provides one channel for media conversion between 1) 10/100/1000Base-TX and 1000Base-SX/LX or 2) 1000Base-SX/LX and 100Base-FX. It can be used as a stand-alone device or with a standard 19” chassis as shown below. Product Overview 10/100/1000Base-TX↔1000Base-SX/LX Media Converter 1000Base-SX/LX↔100Base-FX Media Converter...

  • Page 4: Product Features

    Product Features One-channel media conversion between: 10/100/1000Base-TX and 1000Base-SX/LX 1000Base-SX/LX and 100Base-FX TX port support speed and duplex mode auto-negotiation and auto-MDIX Gigabit Ethernet Fiber media support auto-negotiation and allow either: Multi-mode fiber or Single-mode fiber that using SC connector Fast Ethernet Fiber media allow either: Multi-mode fiber that using SC, ST, VF-45, MT-RJ, or LC connector Single-mode fiber that using SC connector...
  • Page 5 Gigabit Ethernet Media Converter 10/100/1000Base-TX↔1000Base-SX/LX Media Converter LEDs State Indication Steady Power feeding in No power LNK/ACT Steady A valid network connection established. (TX) LNK stands for LINK. Flashing Transmitting and receiving data. ACT stands for ACTIVITY Neither connection nor activity existing. LNK/ACT Steady A valid network connection established.

  • Page 6: Installation

    LEDs State Indication Steady Power feeding in No power LNK/ACT Steady A valid network connection established. LNK stands for LINK. Flashing Transmitting and receiving data. ACT stands for ACTIVITY Neither connection nor activity existing. Installation This chapter gives step-by-step installation instructions for the Converter. Selecting a Site for the Equipment As with any electric device, you should place the equipment where it will not be subjected to extreme temperatures, humidity, or electromagnetic...

  • Page 7: Installing In A Chassis

    Gigabit Ethernet Media Converter Installing in a Chassis The Converter is designed to fit into any of the expansion slots on a rackmount chassis. Step 1: Unscrew the carrier from the desired expansion slot on the chassis. Step 2: Fit the converter onto the carrier. Step 3: When the converter is completely seated onto the carrier, insert the carrier to the guide rails of the expansion slot.

  • Page 8: Specifications

    Specifications Applicable Standards IEEE 802.3 10Base-T IEEE 802.3u 100Base-TX/FX IEEE 802.3ab 1000Base-T IEEE 802.3z 1000Base-SX/LX Fixed Ports 10/100/1000Base-TX port 1000Base-SX/LX port One 1000Base-SX/LX port and one 100Base-FX port Speed 10/20Mbps for half/full-duplex 100/200Mbps for half/full-duplex 2000Mbps for full-duplex Forwarding rate 14,880pps for 10Mbps 148,810pps for 100Mbps 1,488,100pps for 1000Mbps...
